HANDLEBAR W/ SWITCHES - LEVERS (RIGHT) для Suzuki DR-Z400EK7 - 2007 года выпуска
-
№АртикулНазвание
-
157110-14D11 GRIP, THROTTLEGRIP, THROTTLE
-
257100-14D00 CASE ASSY, THROTTLECASE ASSY, THROTTLE
-
309125-05066 SCREW, UPPER (5X25)SCREW, UPPER (5X25)
-
402112-05203 SCREWSCREW
-
557421-36E10 LEVER, BRAKELEVER, BRAKE
-
657431-14500 BOLT, LEVERBOLT, LEVER
-
708316-10063 NUTNUT
-
857430-36E00 BOLT, ADJUSTERBOLT, ADJUSTER
-
957318-14502 SPRINGSPRING
-
1057341-36E00 COVER, RIGHT HANDCOVER, RIGHT HAND
