SKID PLATE для Polaris RANGER XP 900 (POLARIS PURSUIT CAMO (HUNTER DELUXE EDITION) [R16RTU87A9] - 2016 года выпуска`
-
№АртикулНазвание
-
15450877 PLATE-SKID, (LEFT HAND), TTNPLATE-SKID, (LEFT HAND), TTN
-
25450878 PLATE-SKID, (RIGHT HAND), TTNPLATE-SKID, (RIGHT HAND), TTN
-
37556065 WASHER-SKID PLATEWASHER-SKID PLATE
-
47518529 SCREWSCREW
-
55452556 PROTECTOR-UNDER BOX, (LEFT HAND), RGRPROTECTOR-UNDER BOX, (LEFT HAND), RGR
-
65452557 PROTECTOR-UNDER BOX, (RIGHT HAND), RGRPROTECTOR-UNDER BOX, (RIGHT HAND), RGR
-
77519731 SCREWSCREW
-
85452558 GUARD-A ARM, (LEFT HAND), F, RGRGUARD-A ARM, (LEFT HAND), F, RGR
-
95452559 GUARD-A ARM, (RIGHT HAND), F, RGRGUARD-A ARM, (RIGHT HAND), F, RGR
-
105140242 CLAMP-A ARM GUARD, FRCLAMP-A ARM GUARD, FR
-
117556064 WSHR-6.4X18.0X1.6 ZPBWSHR-6.4X18.0X1.6 ZPB
-
127518535 SCREWSCREW
-
135452560 GUARD-A ARM, (LEFT HAND), R, RGRGUARD-A ARM, (LEFT HAND), R, RGR
-
145452561 GUARD-A ARM, (RIGHT HAND), R, RGRGUARD-A ARM, (RIGHT HAND), R, RGR
-
155261708 CLAMP-A ARM GUARD, RR, INNERCLAMP-A ARM GUARD, RR, INNER
-
165261709 CLAMP-A ARM GUARD, RR, OUTERCLAMP-A ARM GUARD, RR, OUTER
-
177518546 SCREWSCREW
