THROTTLE BODY W/ INTAKE MANIFOLD для Polaris IQ WIDETRAK AND EURO (S09PU7ES) - 2009 года выпуска`
-
№АртикулНазвание
-
13131591 SENSOR-THROTTLE POSITIONSENSOR-THROTTLE POSITION
-
21253520 ASM-THROTTLE BODY 43MMASM-THROTTLE BODY 43MM
-
37080909 CLAMP, NARROW BAND(1.77/2.75)CLAMP, NARROW BAND(1.77/2.75)
-
45412476 ADAPTER-THROTTLE BODY 46MMBOREADAPTER-THROTTLE BODY 46MMBORE
-
50451543 BOLTBOLT
-
60452951 INTAKE W/HOLE, NA (W/SENSOR HOLE)INTAKE W/HOLE, NA (W/SENSOR HOLE)
-
60452955 INTAKE NA (W/O SENSOR HOLE)INTAKE NA (W/O SENSOR HOLE)
-
70452959 SENSOR-PRESSURE, NASENSOR-PRESSURE, NA
-
80452957 BOLTBOLT
-
90452952 O-RINGO-RING
Все узлы модели:
- AIR INTAKE SYSTEM
- ALTERNATOR
- BACKREST W/GRAB HANDLE
- BATTERY BOX
- BRAKE CALIPER
- BULKHEAD AND TUNNEL
- CAM CHAIN W/ TENSIONERS
- CLUTCH - PRIMARY
- CLUTCH GUARD
- CONSOLE
- COOLANT RAIL
- COOLING SYSTEM
- CRANKCASE AND CYLINDER ASSEMBLY
- CRANKSHAFT AND BALANCE SHAFT
- DECALS
- DRAG LINK
- DRIVE GEAR W/ PULLEY
- DRIVE SHAFT W/ JACKSHAFT ASM.
- DRIVE TRAIN - SECONDARY CLUTCH W/ DRIVE BELT
- ECU MOUNTING
- ELECTRICAL - SENSORS AND SWITCHES
- ENGINE MOUNTING - LEFT
- EXHAUST SYSTEM
- FENDERS
- FOOTRESTS
- FRONT BUMPER W/NOSEPAN AND TIE ROD BOOT
- FRONT HINGE
- FUEL RAIL
- FUEL TANK W/FUEL LINES
- GAUGE - MULTI FUNCTION
- GEARCASE (1 OF 2)
- GEARCASE (2 OF 2)
- GEARCASE MOUNTING
- HANDLEBAR ASSEMBLY
- HANDLEBAR ASSEMBLY W/ CONTROLS
- HEADLIGHT ASSEMBLY
- HOOD - FILTER/FABRIC
- HOOD - FOAM/FOIL
- IGNITION COILS W/ SPARK PLUGS
- MOUNTING - R.H.
- OIL COOLING SYSTEM
- OIL FILTER
- OIL PUMP ASSEMBLY
- OIL SUMP
- PISTON W/ BEARING
- REAR RACK AND SNOWFLAP
- SEAT
- SEAT RISER
- SHIFT LINKAGE
- SHOCK TOWERS AND PAN BRACE
- SHORT BLOCK
- SIDE PANELS
- SKI ASSEMBLY
- STARTING MOTOR
- STEERING - LOWER W/TIE RODS
- STEERING POST ASSEMBLY
- SUSPENSION - FRONT
- SUSPENSION - FRONT SHOCK TRACK
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - IFS SHOCK
- SUSPENSION - RAIL MOUNTING
- SUSPENSION - REAR SHOCK TRACK
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- SUSPENSION - REAR TRACK SHOCK
- SUSPENSION - SWAYBAR
- TAILLIGHT
- • THROTTLE BODY W/ INTAKE MANIFOLD
- TOOL KIT W/OWNERS MANUAL
- VALVE COVER
- VALVE TRAIN
- VALVES
- WATER PUMP
- WINDSHIELD W/ MIRRORS
- WIRE HARNESS W/COMPONENTS
