SENSORS - SWITCHES - COMPONENTS для Polaris 700 TURBO IQ DRAGON AND EURO (S09PP7FS) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    4011005 POSITION-SWITCH INDICATOR
    POSITION-SWITCH INDICATOR
  • 2
    4011340 SWITCH-POSITION TYP21-670
    SWITCH-POSITION TYP21-670
  • 3
    0451351 VALVE, PRESSURE REGULATOR
    VALVE, PRESSURE REGULATOR
  • 4
    0452957 BOLT
    BOLT
  • 5
    0452956 SENSOR-SPEED
    SENSOR-SPEED
  • 6
    0451350 SENSOR, WATER TEMP.
    SENSOR, WATER TEMP.
  • 7
    4011026 SWITCH-ROLL OVER
    SWITCH-ROLL OVER
  • 8
    7661146 RIVET-3/16 (.751-.875)LF-ALUM
    RIVET-3/16 (.751-.875)LF-ALUM
  • 9
    0451354 SENSOR, PHASE
    SENSOR, PHASE
  • 10
    0451998 BOLT
    BOLT
  • 11
    0451565 SCREW
    SCREW
  • 12
    0451509 SENSOR, KNOCK
    SENSOR, KNOCK
  • 13
    7512095 SCREW (PLENUM)
    SCREW (PLENUM)
  • 13
    7517431 SCREW (AIRBOX)
    SCREW (AIRBOX)
  • 14
    2410422 SENSOR-T MAP (PLENUM)
    SENSOR-T MAP (PLENUM)
  • 14
    2410605 SENSOR-T-MAP (AIRBOX)
    SENSOR-T-MAP (AIRBOX)
  • 15
    0452959 SENSOR, PRESSURE
    SENSOR, PRESSURE
  • 16
    0452957 BOLT
    BOLT
  • 17
    7512026 SCREW
    SCREW
  • 18
    5249291 BRKT-MNT, WASTEGATE VALVE
    BRKT-MNT, WASTEGATE VALVE
  • 19
    4011285 VALVE, ELECTRONIC BOOST CONTROL
    VALVE, ELECTRONIC BOOST CONTROL
  • 20
    3131591 SENSOR-THROTTLE POSITION
    SENSOR-THROTTLE POSITION
  • 21
    4011040 SENSOR-OXYGEN, WIDE BAND
    SENSOR-OXYGEN, WIDE BAND
  • 22
    7542105 NUT HEX
    NUT HEX
  • 23
    7552801 WASHER, SPRING LOCK
    WASHER, SPRING LOCK
  • 24
    7518287 NUT-#10-24 NYLOK INSERT
    NUT-#10-24 NYLOK INSERT
  • 25
    40123581 CONTROLLER-H-BRIDGE
    CONTROLLER-H-BRIDGE
  • 27
    7517263 SCREW, HX/SEMS
    SCREW, HX/SEMS
  • 27
    7541925 NUT, NYLOK 10-24 Y
    NUT, NYLOK 10-24 Y
  • 27
    7555746 WASHER
    WASHER
  • 28
    4011280 SWITCH-AUX SHUT-OFF/POWER
    SWITCH-AUX SHUT-OFF/POWER
  • 29
    2010290 ASM-CONTROL, LEFT HAND, MFG
    ASM-CONTROL, LEFT HAND, MFG
  • 30
    5433291 BUTTON SWITCH HI/LO, LEFT HAND CONTROL
    BUTTON SWITCH HI/LO, LEFT HAND CONTROL
  • 31
    7517441 SCREW, .75
    SCREW, .75
  • 32
    7512078 SCREW, 1.12
    SCREW, 1.12
  • 33
    7517566 SCREW, 1.50
    SCREW, 1.50
  • 34
    2200358 KIT, IGN.SWITCH
    KIT, IGN.SWITCH
  • 35
    7547035 NUT, IGNITION
    NUT, IGNITION
  • 36
    5410611 KEY (SEE NOTE)
    KEY (SEE NOTE)
  • 37
    4012259 ECU-CALIBRATION FST
    ECU-CALIBRATION FST
  • 38
    7542122 NUT-NYLOK
    NUT-NYLOK
  • 39
    2410836 HEATER-GRIP, LO/MED/HI, SHORT
    HEATER-GRIP, LO/MED/HI, SHORT
