ELECTRICAL - MAGNETO ASSEMBLY W/ COIL для Polaris TRAIL TOURING EURO (S08NT5BE) - 2008 года выпуска`
-
№АртикулНазвание
-
13085698 ASM.,SCREW AND WASHERASM.,SCREW AND WASHER
-
23089938 FLYWHEELFLYWHEEL
-
33089937 STATORSTATOR
-
43085697 ASM.,SCREW AND WASHERASM.,SCREW AND WASHER
-
53070163 SPARKPLUG BR9ESSPARKPLUG BR9ES
-
63085935 CAP,SPARK PLUGCAP,SPARK PLUG
-
73086976 CAP,SPARK PLUGCAP,SPARK PLUG
-
83087219 UNIT-HARNESSUNIT-HARNESS
-
93089939 CDI SYSTEM-COMPLETE (INCL. 8)CDI SYSTEM-COMPLETE (INCL. 8)
-
102461060 JUMPER-STUBBER,W/ES (ELECTRIC START)JUMPER-STUBBER,W/ES (ELECTRIC START)
-
113089478 ASM.,IGNITION COIL (INCL. 7)ASM.,IGNITION COIL (INCL. 7)
-
123086751 BOLT-FLANGEBOLT-FLANGE
