SUSPENSION - REAR для Polaris TRAIL RMK FLEET (S08NJ5BSF) - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    7556216 WASHER-.315/.325X.88X.075, FL-Y
    WASHER-.315/.325X.88X.075, FL-Y
  • 2
    7547217 NUT-5/16-24, NYLOK, GR8, Y
    NUT-5/16-24, NYLOK, GR8, Y
  • 3
    7542439 NUT, NYLOK
    NUT, NYLOK
  • 4
    7555806 WASHER, FLAT
    WASHER, FLAT
  • 5
    1590303-244 ASM-WHEEL IDLER, HP, BR SLV MET
    ASM-WHEEL IDLER, HP, BR SLV MET
  • 5
    3514384 BEARING-.7874X1.6535X.4724, NTN
    BEARING-.7874X1.6535X.4724, NTN
  • 5
    7710444 RING, RETAINING
    RING, RETAINING
  • 6
    5432535 SPACER, IDLER
    SPACER, IDLER
  • 7
    7555918 BUSHING
    BUSHING
  • 8
    1594087 ASM., WHEEL, PLAIN(6.38 O.D.)
    ASM., WHEEL, PLAIN(6.38 O.D.)
  • 8
    3514384 BEARING-.7874X1.6535X.4724, NTN
    BEARING-.7874X1.6535X.4724, NTN
  • 8
    7710444 RING, RETAINING
    RING, RETAINING
  • 9
    5333285 SPACER, IDLER, LONG
    SPACER, IDLER, LONG
  • 10
    5020744 SHAFT, IDLER
    SHAFT, IDLER
  • 11
    7556130 WASHER-.406X1.25X.125
    WASHER-.406X1.25X.125
  • 12
    7517731 BOLT, 3/8-16X1.25
    BOLT, 3/8-16X1.25
  • 13
    7517921 SCR-3/8-24X9.875, HX/LP, GR8-Y
    SCR-3/8-24X9.875, HX/LP, GR8-Y
  • 14
    5411955 TRACK, 136'' X 1.25''
    TRACK, 136'' X 1.25''
  • 14
    5222840 CLIP-GUIDE, CAMOPLAST TRACK
    CLIP-GUIDE, CAMOPLAST TRACK
  • 15
    7556242 WASHER-.385X.88X.075, FL-Y THR
    WASHER-.385X.88X.075, FL-Y THR
  • 16
    7517996 SCR-5/16-24X9.75, HWH, SP, GR8-Y
    SCR-5/16-24X9.75, HWH, SP, GR8-Y
  • 17
    7517857 SCR-3/8-24X2.00 HX/CP-GR8-P80Y
    SCR-3/8-24X2.00 HX/CP-GR8-P80Y
  • 18
    7552603 WASHER, SPRING LOCK
    WASHER, SPRING LOCK
  • 19
    7556042 WASHER
    WASHER
  • 20
    7517247 SCREW
    SCREW
  • 21
    5020868 SHAFT
    SHAFT
  • 22
    7555832 WASHER
    WASHER
  • 23
    5334062 SPACER-SHOCK CENTERING
    SPACER-SHOCK CENTERING
  • 24
    5133188 SHAFT-.687X8.456
    SHAFT-.687X8.456
  • 25
    7556210 WSHR-.719X1.250X.065-Y
    WSHR-.719X1.250X.065-Y
  • 26
    7080424 FITTING, LUBRICATION
    FITTING, LUBRICATION
  • 27
    1541635-067 WELD-SHOCK PIVOT ARM, 2.75, BLACK
    WELD-SHOCK PIVOT ARM, 2.75, BLACK
  • 28
    5334042 TUBE-.334X.50X8.515, 1020, NITRO
    TUBE-.334X.50X8.515, 1020, NITRO
  • 29
    1541832-067 WELD-REAR PIVOT ARM, BLACK
    WELD-REAR PIVOT ARM, BLACK
  • 30
    5334162 TUBE-.397X.562X8.515, NITRIDE
    TUBE-.397X.562X8.515, NITRIDE
