HANDLEBAR ASSEMBLY W/ CONTROLS для Polaris IQ TURBO DRAGON EURO (S08PP7FE) - 2008 года выпуска
-
№АртикулНазвание
-
15435394-070 GRIP-HANDLEBAR, BLACKGRIP-HANDLEBAR, BLACK
-
27661624 PIN-RETAININGPIN-RETAINING
-
37710503 RING, RETAININGRING, RETAINING
-
45432970 THROTTLE, LEVER, 35.5MMTHROTTLE, LEVER, 35.5MM
-
42010171 ASM., LEVER, HTR, HI/LO 35.5MMASM., LEVER, HTR, HI/LO 35.5MM
-
54011280 SWITCH-AUX SHUT-OFF/POWERSWITCH-AUX SHUT-OFF/POWER
-
65433345 ADAPTER-BLOCK, THROTTLEADAPTER-BLOCK, THROTTLE
-
75249859-067 BAR-HANDLE, BLACKBAR-HANDLE, BLACK
-
87517238 SCREWSCREW
-
95436554-070 COVER-HANDLEBAR, BLACKCOVER-HANDLEBAR, BLACK
-
104010287 CLIP, DART NYLON, BLACKCLIP, DART NYLON, BLACK
-
115436553-070 SLIDE-HANDLEBAR COVER, BLACKSLIDE-HANDLEBAR COVER, BLACK
-
122410836 HEATER-GRIP, LO/MED/HI, SHORTHEATER-GRIP, LO/MED/HI, SHORT
-
131253274-070 HOOK, HNDLBAR, 45DEG, BLKHOOK, HNDLBAR, 45DEG, BLK
-
147517834 SCR-SOCKET HEAD, SS5/16-18X3.00SCR-SOCKET HEAD, SS5/16-18X3.00
-
155433291 BUTTON SWITCH HI/LO, LEFT HAND CONTROLBUTTON SWITCH HI/LO, LEFT HAND CONTROL
-
162010237 ASM-CONTROL, LEFT HAND, MFGASM-CONTROL, LEFT HAND, MFG
-
177517566 SCREW, 1.50SCREW, 1.50
-
187512078 SCREW, 1.12SCREW, 1.12
-
197517441 SCREW, .75SCREW, .75
-
205630187-067 BLOCK, HANDLEBAR, BLACKBLOCK, HANDLEBAR, BLACK
-
217542122 NUT-NYLOKNUT-NYLOK
-
227081388 CABLE-THROTTLE, FS/FSTCABLE-THROTTLE, FS/FST
-
237511848 SCREWSCREW
-
245432261 HOLDER-WIREHOLDER-WIRE
-
257555727 WASHERWASHER
-
267512465 SCREW, SETSCREW, SET
-
275431592 BLOCK, THROTTLE/BRAKEBLOCK, THROTTLE/BRAKE
-
287710401 RING, RETAININGRING, RETAINING
-
297555730 WASHERWASHER
