STEERING - LOWER W/TIE RODS для Polaris FS IQ TOURING (S08PT7ES) - 2008 года выпуска`
-
№АртикулНазвание
-
17547263 NUT-3/8-24 NYLOKNUT-3/8-24 NYLOK
-
27555806 WASHER, FLATWASHER, FLAT
-
37061057 ROD END-3/8, PL, 75°, 1.00, RIGHT HANDROD END-3/8, PL, 75°, 1.00, RIGHT HAND
-
47542401 NUT, HEX, RIGHT HANDNUT, HEX, RIGHT HAND
-
55334667 ROD-TIEROD-TIE
-
67542424 NUT, LEFT HANDNUT, LEFT HAND
-
77061055 ROD END-3/8, PL, 75° LEFT HAND, 750 STUDROD END-3/8, PL, 75° LEFT HAND, 750 STUD
-
81821419 ASM., ARM-IDLERASM., ARM-IDLER
-
95132106 BUSHING-REDUCER, 12MM TO .385BUSHING-REDUCER, 12MM TO .385
-
103514320 BEARING-BALL, 600ILLUBEARING-BALL, 600ILLU
-
115135452 SPACER-TUBE PITMAN/IDLER ARMSSPACER-TUBE PITMAN/IDLER ARMS
-
127518372 SCR-3/8-24X1.25 TX/TRUSS, GR5-YSCR-3/8-24X1.25 TX/TRUSS, GR5-Y
-
137518277 SCR-3/8-16X3.25 FLG HG5 ZSCR-3/8-16X3.25 FLG HG5 Z
-
147061152 LINK-FIXED, 9.30LINK-FIXED, 9.30
