SUSPENSION - REAR SHOCK TRACK (FOX) для Polaris 600 SWITCHBACK (S08PR6HS) - 2008 года выпуска`
-
№АртикулНазвание
-
7043177 SHOCK-R/T, ALUM, FOXSHOCK-R/T, ALUM, FOX
-
11500598 EYELETEYELET
-
21500599 SHAFTSHAFT
-
31500611 KIT-REBUILDKIT-REBUILD
-
41500161 SCREW/O-RING ASM.SCREW/O-RING ASM.
-
51500602 ASM-BODY CAPASM-BODY CAP
-
61500610 SLEEVESLEEVE
-
71500019 SCREWSCREW
-
81500601 ASM-IFPASM-IFP
-
91500605 COLLAR-INTCOLLAR-INT
-
101500016 NUT, LOCKNUT, LOCK
-
111500608 PISTON-.059PISTON-.059
-
121500017 PLATE, TOP OUTPLATE, TOP OUT
-
131500015 PLATE, BACKUPPLATE, BACKUP
-
141500607 WIRE RINGWIRE RING
-
151500606 SLEEVE-BYPASSSLEEVE-BYPASS
-
161500603 BODYBODY
-
171500609 BUSHING, .35ILG, .595TLGBUSHING, .35ILG, .595TLG
-
181500604 COLLAR-EXTCOLLAR-EXT
-
191500600 ASM-BEARINGASM-BEARING
