HOOD - FOAM/FOIL для Polaris 550 LX (S08ND5BS) - 2008 года выпуска`
-
№АртикулНазвание
-
15812107 FOIL, RIGHT HANDFOIL, RIGHT HAND
-
25812106 FOIL, RIGHT HANDFOIL, RIGHT HAND
-
35810345 FOIL, TAPEFOIL, TAPE
-
45812270 FOAM, REAR, LEFT HANDFOAM, REAR, LEFT HAND
-
55812286 FOAM, FRONT, LEFT HANDFOAM, FRONT, LEFT HAND
-
65813087 FOAM-HOOD, CENTER, EDGEFOAM-HOOD, CENTER, EDGE
-
75813089 FOIL-HOOD, FR RIGHT HAND INNER INTAKEFOIL-HOOD, FR RIGHT HAND INNER INTAKE
-
85813090 FOIL-HOOD, FR RIGHT HAND OUTER INTAKEFOIL-HOOD, FR RIGHT HAND OUTER INTAKE
-
95813088 FOIL-HOOD, RIGHT HAND CENTERFOIL-HOOD, RIGHT HAND CENTER
-
105813093 FOIL-HOOD, RIGHT HAND REAR VENTFOIL-HOOD, RIGHT HAND REAR VENT
Все узлы модели:
- BATTERY BOX
- BRAKE ASSEMBLY
- CARBURETOR ASSEMBLY
- CHAINCASE ASSEMBLY
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CONSOLE
- CRANKCASE ASSEMBLY
- CRANKSHAFT ASSY. W/ PISTON
- CYLINDER ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ DRIVE BELT
- ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FRAME - CHASSIS
- FUEL PUMP
- FUEL SYSTEM
- HANDLEBAR ASSEMBLY W/ CONTROLS
- • HOOD - FOAM/FOIL
- HOOD ASSEMBLY W/ WINDSHIELD
- NOSEPAN ASSEMBLY
- NOSEPAN W/FOIL ASSEMBLY
- OIL PUMP ASSEMBLY
- OIL TANK W/ AIR BOX ASSEMBLY
- RECOIL STARTER W/BLOWER HOUSING
- SEAT W/ TAILLIGHT
- SKI ASSEMBLY
- STARTING MOTOR ASSEMBLY
- STEERING - LOWER
- STEERING POST - HOOP
- SUSPENSION - FRONT
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - RAIL MOUNTING
- SUSPENSION - REAR
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- TOOL KIT
- WINDSHIELD/GUAGES/HOOD RETAINER
