OIL PUMP для Polaris 340 (S08NB3AS) - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    3083141 CLAMP-HOSE
    CLAMP-HOSE
  • 2
    3084467 ASM., PIPE, VINYL, 90MM (INCL. 1)
    ASM., PIPE, VINYL, 90MM (INCL. 1)
  • 3
    3083125 SCREW-AIR VENT
    SCREW-AIR VENT
  • 4
    3083126 PACKING
    PACKING
  • 5
    3089468 ASM., OIL PUMP (INC 3-10,16)
    ASM., OIL PUMP (INC 3-10,16)
  • 6
    3089470 SET, SPRING LEVER
    SET, SPRING LEVER
  • 7
    3083445 COLLAR, CAMSHAFT
    COLLAR, CAMSHAFT
  • 8
    3089469 LEVER, CONTROL
    LEVER, CONTROL
  • 9
    3083121 WASHER-SPRING
    WASHER-SPRING
  • 10
    3083120 NUT
    NUT
  • 11
    3083783 ASM., SCREW AND WASHER
    ASM., SCREW AND WASHER
  • 12
    3083600 GEAR, SMALL
    GEAR, SMALL
  • 13
    3083130 SPACER
    SPACER
  • 14
    3083599 BUSHING
    BUSHING
  • 15
    3083671 SPACER 1, .15MM
    SPACER 1, .15MM
  • 15
    3083672 SPACER 2, .3MM
    SPACER 2, .3MM
  • 15
    3083673 SPACER 3, .6MM
    SPACER 3, .6MM
  • 16
    3083127 O RING
    O RING
