SUSPENSION - COMPRESSION DAMPING RESERVOIR (EDGE) для Polaris SUPERSPORT EDGE (S04NP5BS) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    1500263 HOUSING COMPRESSION DAMP (INCL. 2-9)
    HOUSING COMPRESSION DAMP (INCL. 2-9)
  • 2
    1500223 SCREW
    SCREW
  • 3
    1500224 KNOB DAMP ADJUST
    KNOB DAMP ADJUST
  • 4
    1500253 O-RING
    O-RING
  • 5
    1500226 BALL
    BALL
  • 6
    1500225 SPRING
    SPRING
  • 7
    1500254 DRUM, COMPRESSION DAMPING
    DRUM, COMPRESSION DAMPING
  • 8
    1500227 O-RING
    O-RING
  • 9
    1500228 O-RING
    O-RING
  • 10
    1500325 DAMPENER
    DAMPENER
  • 11
    1500161 SCREW O-RING ASSY
    SCREW O-RING ASSY
  • 12
    1500235 PISTON, FLOAT, ASSY
    PISTON, FLOAT, ASSY
  • 13
    1500236 RING, RETAINING
    RING, RETAINING
  • 14
    1500232 SCREW
    SCREW
  • 15
    1500231 RESERVOIR END CAP ASSY
    RESERVOIR END CAP ASSY
  • 16
    1500230 BEARING, EXTERNAL
    BEARING, EXTERNAL
  • 17
    1500229 SEAL, O-RING
    SEAL, O-RING
  • 18
    1500324 PLATE, DAMPING, 4-HOLE
    PLATE, DAMPING, 4-HOLE
  • 19
    1500233 RING, RETAINING
    RING, RETAINING
  • 20
    1500329 RESERVOIR, WITH GROOVE ASSY (INCL. 2-19)
    RESERVOIR, WITH GROOVE ASSY (INCL. 2-19)
