CHAINCASE ASSEMBLY для Polaris SPORT TOURING (S03SU5BS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 2
    3610030 SEAL, OIL
    SEAL, OIL
  • 3
    7542404 NUT
    NUT
  • 4
    7515551 SCREW
    SCREW
  • 5
    3514309 BEARING, BALL
    BEARING, BALL
  • 6
    7718406 RING, RETAINING
    RING, RETAINING
  • 7
    7555917 WASHER
    WASHER
  • 8
    3221094 SPROCKET (18T)
    SPROCKET (18T)
  • 9
    7571620 WASHER, SPRING
    WASHER, SPRING
  • 10
    7542811 NUT
    NUT
  • 11
    7661203 PIN, COTTER
    PIN, COTTER
  • 12
    1332213 TIGHTENER, CHAINCASE
    TIGHTENER, CHAINCASE
  • 12
    3553002 BEARING
    BEARING
  • 12
    5630123 WHEEL, C/C IDLER
    WHEEL, C/C IDLER
  • 12
    7558702 WASHER THRUST
    WASHER THRUST
  • 12
    7662210 PIN, CHAIN TIGHTENER
    PIN, CHAIN TIGHTENER
  • 12
    5630958 TIGHTENER, CHAINCASE
    TIGHTENER, CHAINCASE
  • 13
    5411207 GASKET, CHAINCASE, LONG
    GASKET, CHAINCASE, LONG
  • 14
    5131454 CVR, CHAINCASE, REV, MACH
    CVR, CHAINCASE, REV, MACH
  • 15
    7558403 WASHER, WROUGHT
    WASHER, WROUGHT
  • 16
    7512492 SCREW
    SCREW
  • 17
    7512242 SCREW
    SCREW
  • 18
    3610029 SEAL, OIL
    SEAL, OIL
  • 19
    1341221-067 SHAFT, SHIFT, (BLACK)
    SHAFT, SHIFT, (BLACK)
  • 20
    7661826 PIN, DOWEL
    PIN, DOWEL
  • 21
    7710415 RING, RETAINER
    RING, RETAINER
  • 22
    2200363 KIT, SHIFT FORK/SHAFT (INCL. 18, 20)
    KIT, SHIFT FORK/SHAFT (INCL. 18, 20)
  • 22
    5130805 FORK, SHIFT
    FORK, SHIFT
  • 23
    5410589 O RING
    O RING
  • 24
    7555877 WASHER, THRUST
    WASHER, THRUST
  • 25
    1341075 ASSY.-PINION GEAR, SPUR
    ASSY.-PINION GEAR, SPUR
  • 26
    3221112 CHAIN, HYVO 68 P, 3/4W
    CHAIN, HYVO 68 P, 3/4W
  • 27
    5130721 PINION GEAR, SPUR ASSY.
    PINION GEAR, SPUR ASSY.
  • 28
    7512019 SCREW
    SCREW
  • 29
    5131770 SHAFT, PINION, W/WRENCH FLATS
    SHAFT, PINION, W/WRENCH FLATS
  • 30
    5243162 BRACKET-CHAIN RETENTION, 7.05
    BRACKET-CHAIN RETENTION, 7.05
  • 31
    7517581 SCREW
    SCREW
  • 32
    7552901 WASHER, SPRING LOCK
    WASHER, SPRING LOCK
  • 33
    5130727 RETAINER, DRIVE COUPLER
    RETAINER, DRIVE COUPLER
  • 34
    7041887 SPRING-COMPRESSION
    SPRING-COMPRESSION
  • 35
    1341410 REVERSE GEAR ASSY.
    REVERSE GEAR ASSY.
  • 36
    5130720 COUPLER, DRIVE
    COUPLER, DRIVE
  • 37
    1341227 SPROCKET ASSY. (40T)
    SPROCKET ASSY. (40T)
  • 38
    7555871 WASHER
    WASHER
  • 39
    7052115 PLUG
    PLUG
  • 40
    7515477 SCREW, CARRIAGE
    SCREW, CARRIAGE
  • 41
    5131455 CHAINCASE, VENTED
    CHAINCASE, VENTED
