SUSPENSION - SHOCK AND RESERVOIR (REAR TRACK) для Polaris 500 XC SP EDGE/EDGE X F/O (S02NP5CS) - 2002 года выпуска`
-
№АртикулНазвание
-
1A7042196 SHOCK, REAR TRACK (REMOTERES, FOX)SHOCK, REAR TRACK (REMOTERES, FOX)
-
11500157 FITTING, ELBOW 90DEG.FITTING, ELBOW 90DEG.
-
21500326 HOSE, ASSY. (3.12 TLG)HOSE, ASSY. (3.12 TLG)
-
31500329 RESERVOIR ASSY. [SEE COMPRESSION DAMPING RESERVOIR]RESERVOIR ASSY. [SEE COMPRESSION DAMPING RESERVOIR]
-
41500256 U, CUPU, CUP
-
51500257 WIPER, U, CUPWIPER, U, CUP
-
61500302 EYELETEYELET
-
71500322 SHAFTSHAFT
-
81500328 BEARING, ASSY., QUAD RINGBEARING, ASSY., QUAD RING
-
92200618 KIT, VALV.PISTON (FOX SHOCK)KIT, VALV.PISTON (FOX SHOCK)
-
101500074 BUMPER, RUBBERBUMPER, RUBBER
-
111500016 NUT, LOCKNUT, LOCK
-
121500319 BODY (8.67 TLG, .58 THD)BODY (8.67 TLG, .58 THD)
-
131500108 O-RING (.103W, 1.549ID)O-RING (.103W, 1.549ID)
-
141500244 BODY, CAP ASSY.BODY, CAP ASSY.
-
155333907 SLEEVE (.385X.560X1.30)SLEEVE (.385X.560X1.30)
-
161500311 SLEEVE (.56X.81X1.28)SLEEVE (.56X.81X1.28)
-
171500307 BUSHING (.35ILG, .63TLG)BUSHING (.35ILG, .63TLG)
-
181500330 CLAMP, HOSE (3.21, 3.25)CLAMP, HOSE (3.21, 3.25)
