SUSPENSION - REAR для Polaris 120 XCR (S00WB1AS) - 2000 года выпуска`
-
№АртикулНазвание
-
15333826 SPACER CARRIER WHEELSPACER CARRIER WHEEL
-
21541403 WHEEL CARRIER (INCL. 5, 4)WHEEL CARRIER (INCL. 5, 4)
-
35132254 SHAFT CARRIERSHAFT CARRIER
-
47710444 RING, RETAININGRING, RETAINING
-
53514012 BEARINGBEARING
-
65811954 STRAP-LIMITER (REAR)STRAP-LIMITER (REAR)
-
77517744 SCREWSCREW
-
87555960 WASHERWASHER
-
97542344 NUT, NYLOCNUT, NYLOC
-
107555726 WASHERWASHER
-
117517227 SCREWSCREW
-
127621512 RIVETRIVET
-
135132253 SHAFT-IDLER (REAR)SHAFT-IDLER (REAR)
-
145241628 BRKT, IDLER, ADJUSTBRKT, IDLER, ADJUST
-
157542451 NUT, NYLOCNUT, NYLOC
-
161541415 RAIL, XTRA LITE 68'' ASSY. (RIGHT)RAIL, XTRA LITE 68'' ASSY. (RIGHT)
-
161541416 RAIL, XTRA LITE 68'' ASSY. (RIGHT)RAIL, XTRA LITE 68'' ASSY. (RIGHT)
-
175333932 SPACER-IDLER 1 1/8 OD X.834 IDSPACER-IDLER 1 1/8 OD X.834 ID
-
181590279-293 WHEEL SCROLLED, 5.35, 20MMIR, ASSY. (INCL. 4, 5)WHEEL SCROLLED, 5.35, 20MMIR, ASSY. (INCL. 4, 5)
-
197571629 WASHERWASHER
-
207512492 SCREWSCREW
-
217512312 BOLTBOLT
-
225433623-070 BLOCK, TOE STOP (BLACK)BLOCK, TOE STOP (BLACK)
-
237515317 BOLTBOLT
-
247552901 LOCK WASHERLOCK WASHER
-
257555958 WASHERWASHER
-
267661621 PIN-HOOD HINGEPIN-HOOD HINGE
-
275521529 SLIDER (BLACK)SLIDER (BLACK)
-
285521499 BUMPER, JOUNCE (FRONT)BUMPER, JOUNCE (FRONT)
-
297515199 SCREWSCREW
-
307670068 NUT, PUSH-ONNUT, PUSH-ON
-
315132256 SHAFT (LOWER)SHAFT (LOWER)
-
325811953 STRAP-LIMITER (FRONT)STRAP-LIMITER (FRONT)
-
335132257 SHAFT TORQUE ARM (UPPER)SHAFT TORQUE ARM (UPPER)
-
347041844-067 SPRING-TORSION (LEFT/BLACK)SPRING-TORSION (LEFT/BLACK)
-
347041845-067 SPRING-TORSION (RIGHT/BLACK)SPRING-TORSION (RIGHT/BLACK)
-
355433507 SLEEVE-TORSION SPRINGSLEEVE-TORSION SPRING
-
361541398-067 TORQUE ARM (BLACK)TORQUE ARM (BLACK)
-
377080424 FITTING, LUBE.FITTING, LUBE.
-
387512307 SCREWSCREW
