CRANKCASE ASSEMBLY для Polaris 120 XCR (S00WB1AS) - 2000 года выпуска

№

Артикул

Название
1

3083568 BOLT, FLANGE

BOLT, FLANGE
2

3086527 CVR, ROCKER

CVR, ROCKER
3

3086528 GASKET, ROCKER COVER

GASKET, ROCKER COVER
4

3086531 GASKET, BREATHER COVER

GASKET, BREATHER COVER
5

3086530 PLATE, BREATHER

PLATE, BREATHER
6

3086529 CVR, BREATHER

CVR, BREATHER
7

3086532 PIPE, RUBBER

PIPE, RUBBER
8

3086125 BOLT, FLANGE

BOLT, FLANGE
9

3083054 PIN, DOWEL

PIN, DOWEL
10

3086946 CRANKCASE (INC. 9, 10, 11, 26, 28)

CRANKCASE (INC. 9, 10, 11, 26, 28)
11

3086510 SEAL, OIL, CRANKCASE

SEAL, OIL, CRANKCASE
12

7052266 FITTING (14MMX1.5-1/4) BARB

FITTING (14MMX1.5-1/4) BARB
13

7080003 CLAMP, HOSE

CLAMP, HOSE
14

8450040-600 FUEL LINE, 1/4 ID(600 CM.)

FUEL LINE, 1/4 ID(600 CM.)
15

7661037 PIN, CLEVIS

PIN, CLEVIS
16

7556152 BONDED SEAL, 14MM, OIL DRAIN

BONDED SEAL, 14MM, OIL DRAIN
17

7052115 PLUG

PLUG
18

2540078 ELBOW JOINT (INCL. NUT)

ELBOW JOINT (INCL. NUT)
19

3086518 SLEEVE, GOVERNOR

SLEEVE, GOVERNOR
20

3086517 GEAR, GOVERNOR

GEAR, GOVERNOR
21

3086519 GAUGE, OIL

GAUGE, OIL
22

3086520 GASKET, OIL GUAGE

GASKET, OIL GUAGE
23

3086966 COVER, MAIN BEARING (INC. 24, 26, 27)

COVER, MAIN BEARING (INC. 24, 26, 27)
24

3086516 SEAL, OIL

SEAL, OIL
25

3086522 BOLT AND WASHER

BOLT AND WASHER
26

3080108 BEARING

BEARING
27

3086947 BEARING, BALL

BEARING, BALL
28

3086511 PIPE

PIPE
29

3082934 STUD

STUD
30

3086513 STUD

STUD
31

3086535 GUIDE, VALVE

GUIDE, VALVE
32

3086526 BOLT, FLANGE

BOLT, FLANGE
33

3086524 HEAD, CYLINDER (INCL. 34, 29, 30, 31)

HEAD, CYLINDER (INCL. 34, 29, 30, 31)
34

3086512 STUD

STUD
35

3086525 GASKET, HEAD

GASKET, HEAD
