REVERSE для Polaris GENESIS I (CA) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    7517897 SCR-M5 X 0.8 X 12, PH, PN
    SCR-M5 X 0.8 X 12, PH, PN
  • 2
    5434061 COVER-MOTOR, REVERSE
    COVER-MOTOR, REVERSE
  • 3
    7547059 NUT, NYLOK
    NUT, NYLOK
  • 4
    7555837 WASHER, FLAT
    WASHER, FLAT
  • 5
    2410341 ASM-MOTOR, GEAR, RVS, 2
    ASM-MOTOR, GEAR, RVS, 2
  • 6
    5411767 O-RING-COVER, REVERSE
    O-RING-COVER, REVERSE
  • 7
    3610085 SEAL-OIL, CR, 528113-91
    SEAL-OIL, CR, 528113-91
  • 8
    5434295 PLATE-MOTOR MOUNT, RVS
    PLATE-MOTOR MOUNT, RVS
  • 9
    7517920 SCR-M5X.8X50, FH, W/O-RING
    SCR-M5X.8X50, FH, W/O-RING
  • 10
    7555839 WASHER, FLAT
    WASHER, FLAT
  • 11
    7552613 WASHER, LOCK
    WASHER, LOCK
  • 12
    7516805 SCREW
    SCREW
  • 13
    7661116 PIN-CLEVIS, 1/4X.875
    PIN-CLEVIS, 1/4X.875
  • 14
    5434062 ARM-LINKAGE, REV GATE
    ARM-LINKAGE, REV GATE
  • 15
    7661010 PIN, COTTER
    PIN, COTTER
  • 16
    7661131 PIN-ROLL, .187X1.00-SS
    PIN-ROLL, .187X1.00-SS
  • 17
    5133560 ARM-LINK, REV MOTOR, ALM
    ARM-LINK, REV MOTOR, ALM
  • 18
    7515368 BOLT
    BOLT
  • 19
    7555874 WASHER, FLAT
    WASHER, FLAT
  • 20
    5020683 COLLAR
    COLLAR
  • 21
    7555866 WASHER
    WASHER
  • 22
    7661117 PIN-CLEVIS, 1/4X1.5
    PIN-CLEVIS, 1/4X1.5
  • 23
    5434049 GATE-REVERSE, DIRECTIONAL W/STP (IF BUILT AFTER 11/10/03)
    GATE-REVERSE, DIRECTIONAL W/STP (IF BUILT AFTER 11/10/03)
  • 23
    5435313 GATE-REVERSE, DIRECTIONAL W/STP (IF BUILT AFTER 11/10/03)
    GATE-REVERSE, DIRECTIONAL W/STP (IF BUILT AFTER 11/10/03)
