EXHAUST SYSTEM для Polaris GENESIS I (CA) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    7052105 FITTING,SCREEN,EXH.
    FITTING,SCREEN,EXH.
  • 2
    7052251 FITTING-INJECTOR, EXHAUST, 090
    FITTING-INJECTOR, EXHAUST, 090
  • 3
    1261259-329 ASM-MANIFOLD, EX LOG W/DEF, BLACK (INCL. 2, 6)
    ASM-MANIFOLD, EX LOG W/DEF, BLACK (INCL. 2, 6)
  • 4
    5811045 GASKET, EXH.FLNG
    GASKET, EXH.FLNG
  • 5
    7517562 SCR-M8 X 1.25 X 95-HX/FL
    SCR-M8 X 1.25 X 95-HX/FL
  • 6
    7052071 FITTING, PIPE
    FITTING, PIPE
  • 7
    5411887 HOSE, COVER, EXHAUST PIPE
    HOSE, COVER, EXHAUST PIPE
  • 8
    7080972 CLAMP-HOSE CONSTANT TORQUE 550
    CLAMP-HOSE CONSTANT TORQUE 550
  • 9
    5132567 TUBE-SPACER, .402 X .5 X 18GA SS23.
    TUBE-SPACER, .402 X .5 X 18GA SS23.
  • 10
    5411547 GROMMET, RBR.MLD.
    GROMMET, RBR.MLD.
  • 11
    7080907 CLAMP, HOSE, 3.75
    CLAMP, HOSE, 3.75
  • 12
    5521546 SHIELD
    SHIELD
  • 13
    5411784 HOSE-PIPE/SILENCER, 3.03 ID
    HOSE-PIPE/SILENCER, 3.03 ID
  • 14
    1261110-329 WELD-EXHAUST PIPE, PWC 2, BLACK
    WELD-EXHAUST PIPE, PWC 2, BLACK
  • 15
    7555841 WASHER, FLAT
    WASHER, FLAT
  • 16
    7552608 WASHER, LOCK
    WASHER, LOCK
  • 17
    7516911 SCREW
    SCREW
  • 18
    5411843 HOSE-SILENCER/RESONATOR
    HOSE-SILENCER/RESONATOR
  • 19
    5410853 STRAP, RUBBER
    STRAP, RUBBER
  • 20
    5243775 HOOK, STRAP, NARROW
    HOOK, STRAP, NARROW
  • 21
    7621479 RIVET
    RIVET
  • 22
    5240134 CLIP, STRAP
    CLIP, STRAP
  • 23
    5433650 RESONATOR-GENESIS, 1200, RIGHT HAND
    RESONATOR-GENESIS, 1200, RIGHT HAND
  • 24
    5812369 FOAM-CRADLE, SILENCER, SP
    FOAM-CRADLE, SILENCER, SP
  • 25
    1261062-067 ASM-SILENCER EXHAUST, BLACK
    ASM-SILENCER EXHAUST, BLACK
  • 26
    5812225 FOAM-SUPPORT, REAR, REVERSE
    FOAM-SUPPORT, REAR, REVERSE
  • 27
    5411842 HOSE-CROSSOVER, PUMP BOX
    HOSE-CROSSOVER, PUMP BOX
  • 28
    5333875 TUBE, 3.0ID X .083 X 4.0
    TUBE, 3.0ID X .083 X 4.0
  • 29
    5412267 HOSE-WATER, 2 3/4'', GATES
    HOSE-WATER, 2 3/4'', GATES
  • 30
    5132457 FTNG, EXH, 2.5ID 1/4-18 NPT
    FTNG, EXH, 2.5ID 1/4-18 NPT
  • 31
    5810529 SEAL, EXH.FITTING
    SEAL, EXH.FITTING
  • 32
    7555838 WASHER, LOCK
    WASHER, LOCK
  • 33
    7555836 WASHER
    WASHER
  • 34
    7515116 SCREW
    SCREW
  • 35
    5433649 RESONATOR-GENESIS, 1200, LEFT HAND
    RESONATOR-GENESIS, 1200, LEFT HAND
  • 36
    5411844 HOSE-RESONATOR, LEFT HAND/RIGHT HAND
    HOSE-RESONATOR, LEFT HAND/RIGHT HAND
