STORAGE COMPARTMENT - FRONT для Polaris MSX 140 (CA) - 2003 года выпуска
-
№АртикулНазвание
-
15434974-412 WINDSHIELD-SMOKIN' CLEARWINDSHIELD-SMOKIN' CLEAR
-
27518042 SCR-M6X1.0X25 TORX TRUSS HD-SSSCR-M6X1.0X25 TORX TRUSS HD-SS
-
35412344 GASKET-MIRROR, LEFT HANDGASKET-MIRROR, LEFT HAND
-
35412345 GASKET-MIRROR, RIGHT HANDGASKET-MIRROR, RIGHT HAND
-
42632518-307 ASM-MIRROR, LEFT HAND, BLUEASM-MIRROR, LEFT HAND, BLUE
-
42632519-307 ASM-MIRROR, RIGHT HAND, CAT BLUEASM-MIRROR, RIGHT HAND, CAT BLUE
-
57556094 WASHERWASHER
-
67546704 NUT, NYLOK, SS.NUT, NYLOK, SS.
-
77081088 LATCHLATCH
-
87552613 WASHER, LOCKWASHER, LOCK
-
97517528 SCREW, SS.SCREW, SS.
-
105134119 PLUNGER-LATCHPLUNGER-LATCH
-
117555841 WASHER, FLATWASHER, FLAT
-
125412299 BUMPER-RUBBER, LATCH POSTBUMPER-RUBBER, LATCH POST
-
137556249 WASHER-FLAT M8X24X2-SSWASHER-FLAT M8X24X2-SS
-
147546804 NUT, HEX, , NYLOKNUT, HEX, , NYLOK
-
167518185 SCR-M8X1.25X35 HX/FL-SSSCR-M8X1.25X35 HX/FL-SS
-
177555835 WASHER, FLAT, S.S.,WASHER, FLAT, S.S.,
-
185133640 STUD-BALL, M8, THREADEDSTUD-BALL, M8, THREADED
-
197061114 ROD END-10MM, STABILUS, PWCROD END-10MM, STABILUS, PWC
-
205133641 PIN-DOWEL, M8X80-SSPIN-DOWEL, M8X80-SS
-
217042260 SPRING-GAS, THRD ENDS, 100#SPRING-GAS, THRD ENDS, 100#
-
222874377 ASM-HINGE, FRONT (INCL. 14, 15, 17, 18, 21, 23)ASM-HINGE, FRONT (INCL. 14, 15, 17, 18, 21, 23)
-
247516807 BOLTBOLT
-
257518187 SCR-M6X1X16 HX/FL-SSSCR-M6X1X16 HX/FL-SS
-
267080703 CLIPCLIP
-
275434520-307 DOOR-COMPARTMENT, CAT BLUEDOOR-COMPARTMENT, CAT BLUE
-
283280399 GAUGE-MFIGAUGE-MFI
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE MOUNTING W/ SHORT BLOCK
- ENHANCED STEERING PERFORMANCE
- EXHAUST SYSTEM
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR W/ COVER
- HULL AND BODY - FOOTWELL PADS
- HULL AND BODY - HOOKS
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD/IGNITION
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD AND STORAGE
- STARTING MOTOR
- STEERING CABLE
- • STORAGE COMPARTMENT - FRONT
- THROTTLE BODY
- TOOL KIT
- WATER SIPHON
