FUEL SYSTEM для Polaris MSX 140 (CA) - 2003 года выпуска
-
№АртикулНазвание
-
15410682 GROMMET, VENTGROMMET, VENT
-
27080483 CABLE TIE, 4 INCHCABLE TIE, 4 INCH
-
37052078 CONNECTORCONNECTOR
-
47080138 CABLE TIECABLE TIE
-
57080476 CLAMP, HOSE, S.S.CLAMP, HOSE, S.S.
-
67051015 VALVE, CHECK, RELIEFVALVE, CHECK, RELIEF
-
77052111 FITTING, TEEFITTING, TEE
-
87052118 VALVE, VACUUM CHECKVALVE, VACUUM CHECK
-
98450104-1525 FUEL LINE-MARINE, 1/4", 250CM RDFUEL LINE-MARINE, 1/4", 250CM RD
-
107052253 ASM., CONNECTOR-3/8X5/16, 90, BNDYASM., CONNECTOR-3/8X5/16, 90, BNDY
-
117052329 FITTING-1/4'', STRAIGHTFITTING-1/4'', STRAIGHT
-
127080482 T-CLIPT-CLIP
-
137052230 FITTING-T, FICHT, LARGE, BRFITTING-T, FICHT, LARGE, BR
-
147052229 FITTING-L, FICHT, LARGEFITTING-L, FICHT, LARGE
-
155411601 O-RING-DFI FITTING, LARGEO-RING-DFI FITTING, LARGE
-
167052227 FITTING-L, FICHT, SMALLFITTING-L, FICHT, SMALL
-
175411599 O-RING-DFI FITTING, SMALLO-RING-DFI FITTING, SMALL
-
197052228 FITTING-T, FICHT, SMALL, BRFITTING-T, FICHT, SMALL, BR
-
207080948 CLAMPCLAMP
-
212872602 SHRADER VALVE, FICHT, W/CAPSHRADER VALVE, FICHT, W/CAP
