MAGNETO для Polaris Freedom 3-Pass - 2003 года выпуска
-
№АртикулНазвание
-
14010172 STATOR ASSY.STATOR ASSY.
-
27517620 SCREWSCREW
-
35411320 O-RINGO-RING
-
45432282 HOLDER, MAGNETHOLDER, MAGNET
-
54010569 FLYWHEEL, ASSY.FLYWHEEL, ASSY.
-
62201228 TIMING SCREWS KITTIMING SCREWS KIT
-
77555907 WASHERWASHER
-
87546909 NUTNUT
-
92460718 HARNESS, 8 WIRE STATORHARNESS, 8 WIRE STATOR
-
104010568 CDI, PROGRAMMED (IF BUILT BEFORE 9/25/02)CDI, PROGRAMMED (IF BUILT BEFORE 9/25/02)
-
104010803 CDI, PROGRAMMED (IF BUILT AFTER 9/25/02)CDI, PROGRAMMED (IF BUILT AFTER 9/25/02)
-
114010175 COIL, IGNITIONCOIL, IGNITION
-
127080471 T-CLIPT-CLIP
-
134010173-42 SPARK PLUG, WIRE (71 CM)SPARK PLUG, WIRE (71 CM)
-
144010173-56 SPARK PLUG, WIRE (71 CM)SPARK PLUG, WIRE (71 CM)
-
157080483 CABLE TIE (4 IN.)CABLE TIE (4 IN.)
-
164020155 CAP, SPARKPLUGCAP, SPARKPLUG
