INTAKE GRATE W/ RIDE PLATE для Polaris Freedom 3-Pass - 2003 года выпуска
-
№АртикулНазвание
-
15133650 SCOOP, INLET 2SCOOP, INLET 2
-
27547003 NUTNUT
-
37555873 WASHER, FLAT NYLONWASHER, FLAT NYLON
-
45810879 GASKET, PITOTGASKET, PITOT
-
57555848 WASHER, FLATWASHER, FLAT
-
67518085 SCREWSCREW
-
75630542-067 GRATE, INLET (BLACK)GRATE, INLET (BLACK)
-
87515155 BOLTBOLT
-
97517267 SCREWSCREW
-
107515126 BOLTBOLT
-
115631080-329 PLATE, RIDE (BLACK)PLATE, RIDE (BLACK)
-
127010083 INSERT, SPONSON / RIDEPLATEINSERT, SPONSON / RIDEPLATE
Все узлы модели:
- AIR INLET - ENGINE AND HULL
- BATTERY BOX
- BILGE PUMP
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- • INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
