CRANKSHAFT W/ PISTONS для Polaris Virage TX 3-Pass - 2002 года выпуска`
-
№АртикулНазвание
-
13023031 CIRCLIP, PISTON (22MM)CIRCLIP, PISTON (22MM)
-
23021164 PIN, PISTON (22MM)PIN, PISTON (22MM)
-
32201706 PISTON 84MM (STD) (INCL.1, 2, 4)PISTON 84MM (STD) (INCL.1, 2, 4)
-
32201707 PISTON 84MM (.25MM O/S) (OPT) (INCL.1, 2, 4)PISTON 84MM (.25MM O/S) (OPT) (INCL.1, 2, 4)
-
32201708 PISTON 84MM (.50MM O/S) (OPT) (INCL. 1, 2, 4)PISTON 84MM (.50MM O/S) (OPT) (INCL. 1, 2, 4)
-
42201449 RING KIT 84MM. (STD)RING KIT 84MM. (STD)
-
42201450 RING KIT 84MM. (.25MM O/S) (OPT)RING KIT 84MM. (.25MM O/S) (OPT)
-
42201451 RING KIT 84MM. (.50MM O/S) (OPT)RING KIT 84MM. (.50MM O/S) (OPT)
-
52201445 CONNECTING, ROD KITCONNECTING, ROD KIT
-
63552112 BEARING, PISTON PINBEARING, PISTON PIN
-
77721117 KEY, WOODRUFFKEY, WOODRUFF
-
87555905 BUSHINGBUSHING
-
95432576 COUPLERCOUPLER
-
107546909 NUTNUT
-
117555907 WASHERWASHER
-
123610044 SEALSEAL
-
137710441 RING, RETAININGRING, RETAINING
-
143585503 BEARING, BALLBEARING, BALL
-
155131744 CRANKWEB (PTO)CRANKWEB (PTO)
-
165131745 CRANKWEB (CENTER)CRANKWEB (CENTER)
-
175131086 LABYRINTHLABYRINTH
-
185131746 CRANKWEB (MAG)CRANKWEB (MAG)
-
195411937 SEAL, SPRINGSEAL, SPRING
-
205410613 O-RINGO-RING
-
215131195 COLLAR, CRANKSHAFTCOLLAR, CRANKSHAFT
-
212201444 CRANKSHAFT ASSY. (INCL. 6, 8, 14-18)CRANKSHAFT ASSY. (INCL. 6, 8, 14-18)
