COOLING SYSTEM для Polaris Virage TX 3-Pass - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    5811317 GASKET
    GASKET
  • 2
    5431444-133 FITTING, THRU HULL (WHITE)
    FITTING, THRU HULL (WHITE)
  • 3
    7080475 CLAMP, HOSE
    CLAMP, HOSE
  • 4
    5521287-18 CONDUIT, FLEX (1.250 ID)
    CONDUIT, FLEX (1.250 ID)
  • 5
    5411335 HOSE, WATER INLET
    HOSE, WATER INLET
  • 6
    5431784 FITTING, TEE
    FITTING, TEE
  • 7
    5411793 HOSE, WATER-IN EXHAUST PIPE
    HOSE, WATER-IN EXHAUST PIPE
  • 8
    5020668 FITTING, INLET WATER
    FITTING, INLET WATER
  • 9
    7052105 FITTING, EXHAUST SCREEN
    FITTING, EXHAUST SCREEN
  • 10
    7080476 CLAMP, HOSE
    CLAMP, HOSE
  • 11
    5411153 HOSE, STINGER
    HOSE, STINGER
  • 12
    7052290 FITTING, INJECTOR EXHAUST
    FITTING, INJECTOR EXHAUST
  • 13
    5410897 HOSE, STINGER FORMED
    HOSE, STINGER FORMED
  • 14
    5521398-42 CONDUIT, FLEX
    CONDUIT, FLEX
  • 15
    7516727 BOLT
    BOLT
  • 16
    7516725 BOLT
    BOLT
  • 17
    1260809-329 MANIFOLD, EXHAUST ASSY. (BLACK)
    MANIFOLD, EXHAUST ASSY. (BLACK)
  • 18
    5020746 FITTING, DRAIN
    FITTING, DRAIN
  • 19
    7080138 CABLE TIE
    CABLE TIE
  • 20
    7051527 PLUG, PIPE
    PLUG, PIPE
  • 21
    7051008 THERMOSTAT (143 F.)
    THERMOSTAT (143 F.)
  • 22
    5412014 GASKET, THERMOSTAT
    GASKET, THERMOSTAT
  • 23
    7556174 WASHER, ANODIZE
    WASHER, ANODIZE
  • 24
    5631136 COVER, THERMOSTAT
    COVER, THERMOSTAT
  • 25
    7041310 SPRING, COMPRESSION
    SPRING, COMPRESSION
  • 26
    5433823 VALVE, POP OFF
    VALVE, POP OFF
  • 27
    5410860 SEAL, O-RING/THERMO/FITTING
    SEAL, O-RING/THERMO/FITTING
  • 28
    5411310 HOSE, WATER OUT (3/4 ID)
    HOSE, WATER OUT (3/4 ID)
  • 29
    5521287-45 CONDUIT, FLEX (1.250 ID)
    CONDUIT, FLEX (1.250 ID)
