SHROUD W/ INSTRUMENTS AND MIRRORS для Polaris Genesis 4-Pass Euro - 2002 года выпуска

‹-+›
  • №
    Артикул
    Название
  • 1
    3280371 GAUGE MFI, ANALOG DIGITAL
    GAUGE MFI, ANALOG DIGITAL
  • 2
    5411738 GASKET MFI
    GASKET MFI
  • 3
    4010281 CONNECTOR 4PIN W/ PLUGS
    CONNECTOR 4PIN W/ PLUGS
  • 4
    8450070-235 LINE, PITOT FORMED
    LINE, PITOT FORMED
  • 5
    7041931 SPRING, MOUNTING MFI
    SPRING, MOUNTING MFI
  • 6
    2201593 MFI, BUTTON REPLACEMENT KIT
    MFI, BUTTON REPLACEMENT KIT
  • 7
    3280342 BEZEL MFI, OVERLAY
    BEZEL MFI, OVERLAY
  • 8
    2653011 LATCH ASSY., CONSOLE
    LATCH ASSY., CONSOLE
  • 9
    5434564-1134 LID CONSOLE, PUSH (BLUE METALLIC)
    LID CONSOLE, PUSH (BLUE METALLIC)
  • 10
    5521596 SEAL, LID
    SEAL, LID
  • 11
    7546705 NUT (6 MM)
    NUT (6 MM)
  • 12
    5812235 PAD
    PAD
  • 13
    7517668 SCREW
    SCREW
  • 14
    7556055 WASHER, LOCK
    WASHER, LOCK
  • 15
    7555831 WASHER, FLAT
    WASHER, FLAT
  • 16
    7546704 NUT, NYLOK
    NUT, NYLOK
  • 17
    7556094 WASHER
    WASHER
  • 18
    5245455 HOOK, LATCH
    HOOK, LATCH
  • 19
    7517669 SCREW
    SCREW
  • 20
    5411557 GASKET MIRROR (LEFT)
    GASKET MIRROR (LEFT)
  • 20
    5411558 GASKET MIRROR (RIGHT)
    GASKET MIRROR (RIGHT)
  • 21
    2631972-070 MIRROR ASSY. (LEFT/BLACK)
    MIRROR ASSY. (LEFT/BLACK)
  • 21
    2631973-070 MIRROR ASSY. (RIGHT/BLACK)
    MIRROR ASSY. (RIGHT/BLACK)
  • 22
    7555834 WASHER
    WASHER
  • 23
    7081055 CABLE CHOKE
    CABLE CHOKE
  • 24
    7546804 NUT, HEX NYLOK
    NUT, HEX NYLOK
  • 25
    7080138 CABLE TIE
    CABLE TIE
  • 26
    5411664 GROMMET DECK, WIRE HARNESS
    GROMMET DECK, WIRE HARNESS
  • 27
    7517539 SCREW
    SCREW
  • 28
    1821213 WELD ASSY., DOOR LATCH POST
    WELD ASSY., DOOR LATCH POST
  • 29
    7555835 WASHER, FLAT
    WASHER, FLAT
  • 30
    7547187 NUT
    NUT
  • 31
    5132781 PIN, LATCH
    PIN, LATCH
  • 32
    5812284 COVER SHROUD (FRONT)
    COVER SHROUD (FRONT)
  • 33
    7511873 SCREW
    SCREW
  • 34
    7555837 WASHER, FLAT
    WASHER, FLAT
  • 35
    7621220 RIVET POP
    RIVET POP
  • 36
    5245451 BRACKET SHROUD COVER, MFI
    BRACKET SHROUD COVER, MFI
  • 37
    7516805 SCREW
    SCREW
  • 38
    7552613 WASHER, LOCK
    WASHER, LOCK
  • 39
    7555839 WASHER, FLAT
    WASHER, FLAT
  • 40
    5434558-1134 SHROUD STEER, CHOKE (BLUE METALLIC)
    SHROUD STEER, CHOKE (BLUE METALLIC)
  • 41
    5812076 BUMPER, DOOR/ SHROUD
    BUMPER, DOOR/ SHROUD
  • 42
    7081037 KNOB
    KNOB
  • 43
    2080005 SCREW
    SCREW
  • 44
    5333698 PIN HINGE
    PIN HINGE
  • 45
    5433384 HINGE
    HINGE
  • 46
    7042007 SPRING, TORTION
    SPRING, TORTION
