CARBURETOR для Polaris Genesis 4-Pass Euro - 2002 года выпуска

  • №
    Артикул
    Название
  • 1A
    1253410 CARBURETOR ASSY.
    CARBURETOR ASSY.
  • 1B
    2200910 CARBURETOR REBUILD KIT (INCL. 9, 17, 23, 40)
    CARBURETOR REBUILD KIT (INCL. 9, 17, 23, 40)
  • 1
    3050136 SCREW
    SCREW
  • 2
    2200687 FUEL PUMP BODY KIT
    FUEL PUMP BODY KIT
  • 3
    2200686 GASKET KIT (FUEL PUMP)
    GASKET KIT (FUEL PUMP)
  • 4
    3050254 NOZZEL
    NOZZEL
  • 5
    3050143 HOSE, FUEL
    HOSE, FUEL
  • 6
    7080138 CABLE TIE
    CABLE TIE
  • 7
    7516816 SCREW
    SCREW
  • 8
    5630546 BASE, SILENCER INTAKE
    BASE, SILENCER INTAKE
  • 9
    5830062 GASKET, CARBURETOR (UPPER)
    GASKET, CARBURETOR (UPPER)
  • 10
    3050258 BLOCK, JET (KEIHIN)
    BLOCK, JET (KEIHIN)
  • 11
    2200734 SYNCH KIT. SCREW
    SYNCH KIT. SCREW
  • 12
    3050156 JOINT, CONNECTING
    JOINT, CONNECTING
  • 13
    3050157 TUBE, RUBBER
    TUBE, RUBBER
  • 14
    2200685 CHECKVALVE KIT, MID RANGE (KEIHIN) [1 PER CARB]
    CHECKVALVE KIT, MID RANGE (KEIHIN) [1 PER CARB]
  • 15
    3050144 SCREEN, FUEL STRAINER
    SCREEN, FUEL STRAINER
  • 16
    2201309 PUMP, ACCEL.KIT (1 PER CARB)
    PUMP, ACCEL.KIT (1 PER CARB)
  • 17
    2200733 NEEDLE VALVE KIT (1 PER CARB)
    NEEDLE VALVE KIT (1 PER CARB)
  • 18
    3050183 JET MAIN, 132 KEIHIN (1 PER CARB)
    JET MAIN, 132 KEIHIN (1 PER CARB)
  • 18
    3050185 JET MAIN, 138 KEIHIN (1 PER CARB)
    JET MAIN, 138 KEIHIN (1 PER CARB)
  • 18
    3050187 JET MAIN, 142 KEIHIN (1 PER CARB)
    JET MAIN, 142 KEIHIN (1 PER CARB)
  • 19
    3050129 JET PILOT, 68 KEIHIN (1 PER CARB)
    JET PILOT, 68 KEIHIN (1 PER CARB)
  • 20
    3050122 JET PILOT, 50 KEIHIN (1 PER CARB)
    JET PILOT, 50 KEIHIN (1 PER CARB)
  • 21
    3050135 SCREW, JET BLOCK COVER
    SCREW, JET BLOCK COVER
  • 22
    3050139 COVER, JET BLOCK
    COVER, JET BLOCK
  • 23
    2200730 DIAPHRAGM JET BLOCK KIT (1 PER CARB)
    DIAPHRAGM JET BLOCK KIT (1 PER CARB)
  • 24
    3050137 SCREW, JET BLOCK (1 PER CARB)
    SCREW, JET BLOCK (1 PER CARB)
  • 25
    3050259 BLOCK, JET (KEIHIN)
    BLOCK, JET (KEIHIN)
  • 26
    3050147 O-RING, JET BLOCK
    O-RING, JET BLOCK
  • 27
    2200689 IDLESCREW KIT (KEIHIN) (1 PER CARB)
    IDLESCREW KIT (KEIHIN) (1 PER CARB)
  • 28
    3050140 CAP, LIMITER
    CAP, LIMITER
  • 29
    3050138 COLLAR
    COLLAR
  • 30
    3050148 O-RING, VALVE SEAT
    O-RING, VALVE SEAT
  • 31
    2200688 CHECKVALVE KIT, MAIN (KEIHIN) (1 PER CARB)
    CHECKVALVE KIT, MAIN (KEIHIN) (1 PER CARB)
  • 32
    2200731 IDLESTOP SCREW KIT
    IDLESTOP SCREW KIT
  • 33
    3050252 NOZZLE (MAG) (KEIHIN)
    NOZZLE (MAG) (KEIHIN)
  • 34
    3050261 HOSE, FUEL (ACCEL PUMP)
    HOSE, FUEL (ACCEL PUMP)
  • 35
    3050142 HOSE, FUEL (ACCEL PUMP)
    HOSE, FUEL (ACCEL PUMP)
  • 36
    3050141 FITTING, T
    FITTING, T
  • 37
    3050164 PLATE, CON (KEIHIN)
    PLATE, CON (KEIHIN)
  • 38
    3050159 SCREW, CONNECT PLATE
    SCREW, CONNECT PLATE
  • 39
    3050253 NOZZLE (CENTER) (KEIHIN)
    NOZZLE (CENTER) (KEIHIN)
  • 40
    5830043 GASKET, CARBURETOR
    GASKET, CARBURETOR
