SEAT для Polaris Virage TX 3-Pass - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    7516806 BOLT
    BOLT
  • 2
    7555839 WASHER, FLAT
    WASHER, FLAT
  • 3
    5211314 PLATE, SEATBASE LATCH
    PLATE, SEATBASE LATCH
  • 4
    7042036 SPRING, SEATBASE LATCH
    SPRING, SEATBASE LATCH
  • 5
    5433779 HANDLE, SEAT LATCH W/HOLES
    HANDLE, SEAT LATCH W/HOLES
  • 6
    7621478 RIVET
    RIVET
  • 7
    5812025 STRAP, SEAT LATCH
    STRAP, SEAT LATCH
  • 8
    5411807 SEAL, SEAT (REAR)
    SEAL, SEAT (REAR)
  • 9
    2682774-292 SEAT ASSY., VIRAGE (REAR)
    SEAT ASSY., VIRAGE (REAR)
  • 10
    7080914 CABLE, LIMITER HINGE
    CABLE, LIMITER HINGE
  • 11
    7661044 RIVET
    RIVET
  • 12
    7517805 SCREW
    SCREW
  • 13
    7555838 WASHER, LOCK
    WASHER, LOCK
  • 14
    7517806 SCREW
    SCREW
  • 15
    5431357 PLATE, LATCH BOTTOM SEAT BASE
    PLATE, LATCH BOTTOM SEAT BASE
  • 16
    5431358 HANDLE, SEAT BASE LATCH
    HANDLE, SEAT BASE LATCH
  • 17
    5431359 PLATE, TOP, SEATBASE LATCH
    PLATE, TOP, SEATBASE LATCH
  • 18
    7555846 WASHER, FLAT
    WASHER, FLAT
  • 19
    7552607 WASHER, LOCK
    WASHER, LOCK
  • 20
    7542454 NUT, HEX
    NUT, HEX
  • 21
    2682773-292 SEAT ASSY., MAIN VIRAGE
    SEAT ASSY., MAIN VIRAGE
  • 22
    5521490 BUMPER
    BUMPER
  • 23
    5245090 WASHER, SEAT STRAP 2 HOLE
    WASHER, SEAT STRAP 2 HOLE
  • 24
    2682677-303 STRAP, SEAT VIRAGE 4 HOLE (BLACK)
    STRAP, SEAT VIRAGE 4 HOLE (BLACK)
  • 25
    5521536 SEAL, SEAT MAIN
    SEAL, SEAT MAIN
  • 26
    7661108 RIVET, POP
    RIVET, POP
  • 27
    5020753 PLUNGER, LATCH
    PLUNGER, LATCH
  • 28
    1013431 HINGE ASSY., SEAT VIRAGE
    HINGE ASSY., SEAT VIRAGE
  • 29
    7517669 SCREW
    SCREW
  • 30
    7517717 SCREW
    SCREW
