ELECTRICAL BOX для Polaris Virage TX 3-Pass - 2001 года выпуска`
-
№АртикулНазвание
-
12460955 HARNESS, MAIN VIRAGE W/O SPLICEHARNESS, MAIN VIRAGE W/O SPLICE
-
27080483 CABLE TIE (4 IN.)CABLE TIE (4 IN.)
-
37080138 CABLE TIECABLE TIE
-
45521287-53 CONDUIT, FLEX (1.250ID)CONDUIT, FLEX (1.250ID)
-
55410346 INSULATOR, CABLE SOL.INSULATOR, CABLE SOL.
-
67546705 NUT (6 MM.)NUT (6 MM.)
-
77552613 WASHER, LOCKWASHER, LOCK
-
84010401 SOLENOID, STARTERSOLENOID, STARTER
-
97517671 SCREWSCREW
-
107546704 NUT, NYLOKNUT, NYLOK
-
114060161 FUSE (3 AMP)FUSE (3 AMP)
-
124060111 FUSEFUSE
-
132460928 HARNESS, JUMPERHARNESS, JUMPER
-
145432503 ELECTRICAL BOX PLASTIC ASSY.ELECTRICAL BOX PLASTIC ASSY.
-
155333544 PIN, LATCHPIN, LATCH
-
164010379 CONTROLLER, IGNITIONCONTROLLER, IGNITION
-
172410250 STRAP ASSY., GROUNDING W/FUSESSTRAP ASSY., GROUNDING W/FUSES
-
187547061 NUT, NYLOKNUT, NYLOK
-
197555837 WASHER, FLATWASHER, FLAT
-
207512042 BOLTBOLT
-
214010648 REGULATOR, 1 BUTTONREGULATOR, 1 BUTTON
-
227547059 NUT, NYLOKNUT, NYLOK
-
234010238 CABLE, BATTERY/SOLENOIDCABLE, BATTERY/SOLENOID
-
244010237 CABLE-SOLENOID/STARTERCABLE-SOLENOID/STARTER
-
255411491 O-RINGO-RING
-
267080461 BOOT, THREADED (RED)BOOT, THREADED (RED)
-
277515113 BOLTBOLT
-
287555836 WASHERWASHER
-
295432574 PLATE, STATOR 1 HOLEPLATE, STATOR 1 HOLE
-
307077691 DECAL, ''RESET ELEC SYSTEM''DECAL, ''RESET ELEC SYSTEM''
-
312460717 HARNESS, 9 WIRE STATORHARNESS, 9 WIRE STATOR
-
325433119 COVER, ACCESSORY E-BOXCOVER, ACCESSORY E-BOX
-
335432569 SEALSEAL
-
345244369 BRACKET, COILBRACKET, COIL
-
354010342 COIL, IGNITIONCOIL, IGNITION
-
362410201 BOARD ASSY., TERMINALBOARD ASSY., TERMINAL
-
372434011 CIRKUT, BREAKER (15A.)CIRKUT, BREAKER (15A.)
-
382632137 ELECTRICAL BOX, IGNITION ASSY. (INCL. 14, 15, 32, 33)ELECTRICAL BOX, IGNITION ASSY. (INCL. 14, 15, 32, 33)
-
395411235 GROMMETGROMMET
-
405432502 CAP, GROMMETCAP, GROMMET
-
417517825 SCREWSCREW
