SHROUD W/ INSTRUMENTS AND MIRRORS для Polaris Genesis 4-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
13280292 GAUGE, MFD ANALOG/DIGITALGAUGE, MFD ANALOG/DIGITAL
-
25411738 GASKET, MFIGASKET, MFI
-
34010281 CONNECTOR, DEUTCHE 4PIN W/PLUGSCONNECTOR, DEUTCHE 4PIN W/PLUGS
-
48450070-235 PILOT, LINE FORMED (90 DEG/345CM)PILOT, LINE FORMED (90 DEG/345CM)
-
57041931 SPRING, MOUNTING MFISPRING, MOUNTING MFI
-
62201593 MFI, BUTTON REPLACEMENT KITMFI, BUTTON REPLACEMENT KIT
-
73280342 BEZEL MFI, OVERLAYBEZEL MFI, OVERLAY
-
85433709-305 CONSOLE, LID KITCONSOLE, LID KIT
-
97041754 SPRING, TORSION CONSOLESPRING, TORSION CONSOLE
-
105521478 SEAL, LID CONSOLESEAL, LID CONSOLE
-
117546705 NUT (6 MM)NUT (6 MM)
-
125811783 PAD, CONSOLEPAD, CONSOLE
-
137517668 SCREWSCREW
-
147556055 WASHER, LOCKWASHER, LOCK
-
157555831 WASHER, FLATWASHER, FLAT
-
162080005 SCREWSCREW
-
172080004 KNOB, CHOKEKNOB, CHOKE
-
187516609 SCREWSCREW
-
195211865 PLATE, HOOK CONSOLEPLATE, HOOK CONSOLE
-
205411557 GASKET, MIRROR (LEFT)GASKET, MIRROR (LEFT)
-
205411558 GASKET, MIRROR (RIGHT)GASKET, MIRROR (RIGHT)
-
212631972-070 MIRROR ASSY. (LEFT/BLACK)MIRROR ASSY. (LEFT/BLACK)
-
212631973-070 MIRROR ASSY. (RIGHT/BLACK)MIRROR ASSY. (RIGHT/BLACK)
-
227555834 WASHERWASHER
-
237661042 RIVET, POPRIVET, POP
-
241820725 MOUNT, SHROUDMOUNT, SHROUD
-
257546804 NUT, HEX NYLOKNUT, HEX NYLOK
-
267546704 NUT, NYLOKNUT, NYLOK
-
277555839 WASHER, FLATWASHER, FLAT
-
287541931 NUT, HEXNUT, HEX
-
297080788 CABLE, CHOKE THK NECKCABLE, CHOKE THK NECK
-
305244673 BRACKET, SUPPORT SHROUDBRACKET, SUPPORT SHROUD
-
317516717 BOLTBOLT
-
325411664 GROMMET DECK, WIRE HARNESSGROMMET DECK, WIRE HARNESS
-
332690151 STRAP, TOOL KIT (LOWER)STRAP, TOOL KIT (LOWER)
-
345433210-070 COVER WIRE, SHROUD (BLACK)COVER WIRE, SHROUD (BLACK)
-
362690150 STRAP, TOOL KIT (UPPER)STRAP, TOOL KIT (UPPER)
-
377710517 RING RETAINING (.25 STUD)RING RETAINING (.25 STUD)
-
387516805 SCREWSCREW
-
397552613 WASHER, LOCKWASHER, LOCK
-
405433699-305 SHROUD, W/LID KITSHROUD, W/LID KIT
-
415812076 BUMPER, DOOR/SHROUDBUMPER, DOOR/SHROUD
-
425244670 PLATE, LATCH RECEIVERPLATE, LATCH RECEIVER
-
437555837 WASHER, FLATWASHER, FLAT
-
447517818 SCREWSCREW
-
457512045 BOLTBOLT
-
465811552 GASKET, HOOK CONSOLEGASKET, HOOK CONSOLE
-
475433266 HOOK, CONSOLE LATCH (1/4 TURN)HOOK, CONSOLE LATCH (1/4 TURN)
-
485333698 PIN, HINGEPIN, HINGE
-
495433384 HINGE, PIN (3/16 )HINGE, PIN (3/16 )
-
502632234 LATCH ASSY., CONSOLE (1/4 TURN)LATCH ASSY., CONSOLE (1/4 TURN)
