TRANSMISSION (6 SPEED) для Polaris HAMMER S [V11HS36] - 2011 года выпуска`
-
№АртикулНазвание
-
11332815 ASM., COUNTERSHAFT, 6-SPEED (INCL. 2-12)ASM., COUNTERSHAFT, 6-SPEED (INCL. 2-12)
-
26230453 GEAR, COMMON, COUNTERSHAFTGEAR, COMMON, COUNTERSHAFT
-
35247690 WASHER, THRUSTWASHER, THRUST
-
47710641 RING, RETAININGRING, RETAINING
-
56230419 GEAR, 4TH COUNTERSHAFTGEAR, 4TH COUNTERSHAFT
-
63514608 BEARING, NEEDLE, SPLIT, 28X32X17BEARING, NEEDLE, SPLIT, 28X32X17
-
77710525 RING, RETAININGRING, RETAINING
-
86230416 GEAR, 2ND/3RD, COUNTERSHAFTGEAR, 2ND/3RD, COUNTERSHAFT
-
96230421 GEAR 6TH COUNTERSHAFTGEAR 6TH COUNTERSHAFT
-
107556533 WASHER-THRUST, 40.0X52.0X2.0WASHER-THRUST, 40.0X52.0X2.0
-
117556534 WASHER-WAVE, 40.0X52.0X0.56WASHER-WAVE, 40.0X52.0X0.56
-
126230452 GEAR, COUNTERSHAFT, 1STGEAR, COUNTERSHAFT, 1ST
-
131332817 ASM., MAINSHAFT, 6 SPEED, WIDE (INCL. 3, 7, 14-20)ASM., MAINSHAFT, 6 SPEED, WIDE (INCL. 3, 7, 14-20)
-
146230460 SHAFT, MAIN, WIDESHAFT, MAIN, WIDE
-
153584006 BEARING, ROLLERBEARING, ROLLER
-
166230415 GEAR, 1ST MAINSHAFTGEAR, 1ST MAINSHAFT
-
176230461 GEAR, 6TH MAINSHAFTGEAR, 6TH MAINSHAFT
-
186230455 GEAR, 2ND MAINSHAFTGEAR, 2ND MAINSHAFT
-
196230456 GEAR, 3RD MAINSHAFTGEAR, 3RD MAINSHAFT
-
206230457 GEAR, 4TH MAINSHAFTGEAR, 4TH MAINSHAFT
-
217710632 RING, RETAINING, INT, 1-3/8 LHT DUTYRING, RETAINING, INT, 1-3/8 LHT DUTY
-
241332799 ASM., INPUT SHAFT AND GEAR (INCL. 21, 22, 23)ASM., INPUT SHAFT AND GEAR (INCL. 21, 22, 23)
-
255253665-010 WASHER, THRUST, SHIM, .10WASHER, THRUST, SHIM, .10
-
255253665-020 WASHER, THRUST, SHIM, .20WASHER, THRUST, SHIM, .20
-
255253665-030 WASHER, THRUST, SHIM, .30WASHER, THRUST, SHIM, .30
-
255253665-040 WASHER, THRUST, SHIM, .40WASHER, THRUST, SHIM, .40
-
255253665-050 WASHER, THRUST, SHIM, .50WASHER, THRUST, SHIM, .50
-
263514681 BEARING-BALL, DIA 4.0BEARING-BALL, DIA 4.0
