FUEL SYSTEM для Polaris STANDARD CRUISER (49 STATE) [V99CB15DA] - 1999 года выпуска
-
№АртикулНазвание
-
11080004-1084 TANK,FUEL (KYSO BLUE)TANK,FUEL (KYSO BLUE)
-
11080004-1088 TANK,FUEL (ANTARES RED)TANK,FUEL (ANTARES RED)
-
25830147 SHIELD-HEAT,FUEL TANKSHIELD-HEAT,FUEL TANK
-
35131511 CAP,FUEL SCAP,FUEL S
-
47517405 SCREWSCREW
-
57556052 WASHER,CUSHIONWASHER,CUSHION
-
65411324 ISOLATOR,R.TANK MOUNTISOLATOR,R.TANK MOUNT
-
72520147 HOSE-VENT,FUEL TANKHOSE-VENT,FUEL TANK
-
87080829 CLAMP-HOSE,.375, BLACKCLAMP-HOSE,.375, BLACK
-
95811518 GASKET,SENDER TANK SGASKET,SENDER TANK S
-
104110231 SENDER,FUEL LEVELSENDER,FUEL LEVEL
-
117080476 CLAMP, HOSE, S.S.CLAMP, HOSE, S.S.
-
125411399 HOSE,FUEL,MANIFOLD/FILTER SHOSE,FUEL,MANIFOLD/FILTER S
-
132530031 FILTER,FUELFILTER,FUEL
-
147080795 CLAMP-HOSE BAND,5/8'OD UMPCLAMP-HOSE BAND,5/8'OD UMP
-
155411405 HOSE, RIGHT HAND,FUELTANK SHOSE, RIGHT HAND,FUELTANK S
-
167080790 CLAMP,HOSE,DBL.BANDCLAMP,HOSE,DBL.BAND
-
171500199 O-RINGO-RING
-
172520131 QUICKDISC,FUELFEED,MALE,TEEQUICKDISC,FUELFEED,MALE,TEE
-
185411404 HOSE, LEFT HAND,FUELTANK SHOSE, LEFT HAND,FUELTANK S
-
192520136 QUICKDISC,,FUELPUMP,FEMALEQUICKDISC,,FUELPUMP,FEMALE
-
207080474 CLAMP, HOSECLAMP, HOSE
-
215411402 HOSE,FUEL PUMP/RAILHOSE,FUEL PUMP/RAIL
-
227547041 NUT SNUT S
-
235211889-067 BRKT,FUELPUMP TOP, BLACKBRKT,FUELPUMP TOP, BLACK
-
242520128 PUMP,FUELPUMP,FUEL
-
255411401 HOSE,FUEL FILTER/PUMP SHOSE,FUEL FILTER/PUMP S
-
267556064 WASHERWASHER
-
275830148 SHIELD,HEAT,FUEL PUMP (FUEL PUMP)SHIELD,HEAT,FUEL PUMP (FUEL PUMP)
-
282530028 FILTER,FUEL,HI-PRESSURE (HIGH PRESSURE)FILTER,FUEL,HI-PRESSURE (HIGH PRESSURE)
-
295131506 DISC-QUICK,FUELTANK,FEMALEDISC-QUICK,FUELTANK,FEMALE
-
301500199 O-RINGO-RING
-
305131507 FUELLINE,QUICK DISC,MALEFUELLINE,QUICK DISC,MALE
-
315411403 HOSE,FUEL,RAIL/TANK RTN. S (RAIL/TANK RETURN)HOSE,FUEL,RAIL/TANK RTN. S (RAIL/TANK RETURN)
-
321253174 INJECTOR, FUELINJECTOR, FUEL
-
321500198 O-RINGO-RING
-
332520132 RAIL,FUEL SRAIL,FUEL S
-
347517483 SCREW,BTNHD,M5X12SCREW,BTNHD,M5X12
-
355432577 BUSHING,FUEL SENDER SBUSHING,FUEL SENDER S
-
365830163 SHIELD,HEAT,FUEL TANK,LEFTSHIELD,HEAT,FUEL TANK,LEFT
-
377547045 NUT SNUT S
-
385411317 PAD,FUELTANK FRAME,FRONTPAD,FUELTANK FRAME,FRONT
-
395830164 SHIELD,HEAT,FUEL TANK,RIGHTSHIELD,HEAT,FUEL TANK,RIGHT
