GEARCASE для Polaris SPORTSMAN 1000 XP EU (HAVASU RED PEARL) [A18SXE95FR] - 2018 года выпуска`
-
№АртикулНазвание
-
11333482 ASM-TRANS,BOSS/LUK,CLSD RATIO [INCL. ALL]ASM-TRANS,BOSS/LUK,CLSD RATIO [INCL. ALL]
-
23234756 PLUG, M18 X 1.5 MAGNETICPLUG, M18 X 1.5 MAGNETIC
-
33234309 SCREW, TORX PAN HD M6 X 1 X 16SCREW, TORX PAN HD M6 X 1 X 16
-
43234898 SCREW, HEX FLANGE HEAD M8 X 1.25 X 30SCREW, HEX FLANGE HEAD M8 X 1.25 X 30
-
53234634 SCREW, HEX FLANGE HEAD M10 X 1.5 X 30SCREW, HEX FLANGE HEAD M10 X 1.5 X 30
-
63233961 NUT, LOCK HEX FLANGE NYLON 45428NUT, LOCK HEX FLANGE NYLON 45428
-
73234636 WASHER, THRUST 0.5 X 0.937 X 0.063WASHER, THRUST 0.5 X 0.937 X 0.063
-
83234637 WASHER, THRUST 0.625 X 1 X 0.063WASHER, THRUST 0.625 X 1 X 0.063
-
93234330 PIN, DOWEL 6 X 20PIN, DOWEL 6 X 20
-
103233106 RING, RETAINING BASIC EXTERNAL 0.984RING, RETAINING BASIC EXTERNAL 0.984
-
113233834 RING, SNAPRING, SNAP
-
123233699 RING RETAINING, IRR 7200-118RING RETAINING, IRR 7200-118
-
133234318 RING, RETAINING EXTERNAL SHR-66RING, RETAINING EXTERNAL SHR-66
-
143234327 RING, RETAINING BASIC EXTERNAL SHR-106RING, RETAINING BASIC EXTERNAL SHR-106
-
153234741 RING, RETAINING BASIC INTERNAL, 62MMRING, RETAINING BASIC INTERNAL, 62MM
-
163234639 RING, RETAINING BASIC EXTERNAL, SHR-50RING, RETAINING BASIC EXTERNAL, SHR-50
-
173234641 RING, RETAINING EXTERNAL USC-112RING, RETAINING EXTERNAL USC-112
-
183234642 WASHER, THRUST 0.446 X 0.88 X 0.025WASHER, THRUST 0.446 X 0.88 X 0.025
-
192204343 KIT, LUK INPUT SHAFT PACKKIT, LUK INPUT SHAFT PACK
-
203234248 WASHER, THRUST 1.3 X 0.995 X 0.065WASHER, THRUST 1.3 X 0.995 X 0.065
-
213234643 SHIM, 1.35 OD X 0.818 IDSHIM, 1.35 OD X 0.818 ID
-
223234644 SHIM, 1.17 OD X 0.675 IDSHIM, 1.17 OD X 0.675 ID
-
233234646 WASHER, THRUST 1.568 OD X .1.110 IDWASHER, THRUST 1.568 OD X .1.110 ID
-
243234757 WASHER, THRUST ?33 X ?29 X 1.5WASHER, THRUST ?33 X ?29 X 1.5
-
253233018 BEARING, BALL, 6204 C3 20X47X14BEARING, BALL, 6204 C3 20X47X14
-
263233019 BEARING, BALL, 6205 C3 25X52X15BEARING, BALL, 6205 C3 25X52X15
-
273233020 BEARING, BALL, 6305 C3, 25 X 62 X 17BEARING, BALL, 6305 C3, 25 X 62 X 17
-
283234651 BEARING, BALL, 6304 C3 20X52X15BEARING, BALL, 6304 C3 20X52X15
-
293234274 BEARING, BALL, 6203 C3 17X40X12BEARING, BALL, 6203 C3 17X40X12
-
303234759 BEARING, NEEDLE, SPLIT CAGEBEARING, NEEDLE, SPLIT CAGE
-
313234652 BEARING, BALL 6303, 17 X 47 X 14BEARING, BALL 6303, 17 X 47 X 14
-
323234655 BEARING, NEEDLE, CAGE ASSY 20 X 24 X 10BEARING, NEEDLE, CAGE ASSY 20 X 24 X 10
-
333234656 BEARING, NEEDLE, 28 X 33 X 13BEARING, NEEDLE, 28 X 33 X 13
-
343234687 SPRING, COMPRESSION, 0.648 O.D. X 1.33SPRING, COMPRESSION, 0.648 O.D. X 1.33
-
353234688 SPRING, WAVE, 1.6 ID X 0.375SPRING, WAVE, 1.6 ID X 0.375
-
363234787 SPRING, PARK PAWL TORSIONSPRING, PARK PAWL TORSION
-
373234790 SPRING, COMPRESSION 0.45 OD X 1.58SPRING, COMPRESSION 0.45 OD X 1.58
-
383235790 GEARCASE GTO COVER, MACH.GEARCASE GTO COVER, MACH.
-
393235196 BELLEFT HANDOUSING, MACHBELLEFT HANDOUSING, MACH
-
403235428 GEARCASE, MAIN, GTO MACHGEARCASE, MAIN, GTO MACH
-
413234692 PAWL, PARKPAWL, PARK
-
423234694 GEAR, SECTOR 38TGEAR, SECTOR 38T
-
433234695 BULLET, DETENTBULLET, DETENT
-
443234998 SPROCKET, 44 TOOTHSPROCKET, 44 TOOTH
-
453234774 SHAFT, REVERSE 53TSHAFT, REVERSE 53T
-
463233265 BEARING BALL 6007 C3 35 X 62 X 14BEARING BALL 6007 C3 35 X 62 X 14
-
473235133 GEAR, HELICAL 42TGEAR, HELICAL 42T
-
483234755 PLUG, M18 X 1.5PLUG, M18 X 1.5
-
493235063 SHAFT, INPUT 25T REMSHAFT, INPUT 25T REM
-
503235194 SHAFT, INPUTSHAFT, INPUT
-
513235789 SHAFT, OUTPUT REARSHAFT, OUTPUT REAR
-
523234230 TUBE, VENT, 90 -1/4 IN HOSETUBE, VENT, 90 -1/4 IN HOSE
-
533234706 GEAR, 67TGEAR, 67T
-
543234707 SPROCKET 48T, 6-FACESPROCKET 48T, 6-FACE
-
553235544 SPROCKET, 23TSPROCKET, 23T
-
563234712 SHAFT, SHIFT BELLCRANKSHAFT, SHIFT BELLCRANK
-
573234714 RAIL, SHIFT SHAFTRAIL, SHIFT SHAFT
-
583234715 PLUG, DETENTPLUG, DETENT
-
593234716 RAIL, PARK SHAFTRAIL, PARK SHAFT
-
603234718 DOG, ENGAGEMENT GTO, LOWDOG, ENGAGEMENT GTO, LOW
-
613235341 DOG, ENGAGEMENT GTO, REV/LOWDOG, ENGAGEMENT GTO, REV/LOW
-
623235342 FORK, SHIFTFORK, SHIFT
-
633234765 KNOCK PIPEKNOCK PIPE
-
643234766 FORK, SHIFTFORK, SHIFT
-
653235190 DOG, ENGAGEMENT GTO, HIGHDOG, ENGAGEMENT GTO, HIGH
-
663234767 SUBASSY, SWITCH SHAFTSUBASSY, SWITCH SHAFT
-
673235788 SUBASSY OUTPUT, FRONT W/BEARINGS (#26)SUBASSY OUTPUT, FRONT W/BEARINGS (#26)
-
683235191 SUBASSEMBLY, PRIMARY SHAFT W/BEARINGS (#46 & #25)SUBASSEMBLY, PRIMARY SHAFT W/BEARINGS (#46 & #25)
-
692204268 KIT, GTO, PRIMARY SHIM PACKKIT, GTO, PRIMARY SHIM PACK
-
703234724 BELLCRANK, 15T SPLINEBELLCRANK, 15T SPLINE
-
713234725 DEFLECTOR, OILDEFLECTOR, OIL
-
723235198 SUBASSY BEARING COVER W/SCREWS (#3)SUBASSY BEARING COVER W/SCREWS (#3)
-
733235508 WASHER, RIBBEDWASHER, RIBBED
-
743234737 CHAIN, SILENT, TYPE 101, .25P X .40W X 58LCHAIN, SILENT, TYPE 101, .25P X .40W X 58L
-
753234738 CHAIN SILENT, 0.5 X .375P X 64PCHAIN SILENT, 0.5 X .375P X 64P
-
763233835 SWITCH, ROTARY 6-PIN ITWSWITCH, ROTARY 6-PIN ITW
-
773234302 O-RING, -113O-RING, -113
-
783233828 O-RING, -14 VITONO-RING, -14 VITON
-
793234729 O-RING, 0.53 I.D X 0.082 WIDEO-RING, 0.53 I.D X 0.082 WIDE
-
803234730 O-RING - N70, 9.5 MM X 2 MMO-RING - N70, 9.5 MM X 2 MM
-
813234769 SEAL, 35 X 62 X 8SEAL, 35 X 62 X 8
-
823234892 SEAL, TRIPLE LIP 0.984X1.850X0.315 VITONSEAL, TRIPLE LIP 0.984X1.850X0.315 VITON
-
832877606 LABEL, OILLABEL, OIL
-
844013908 SENSOR, SPEEDSENSOR, SPEED
