WIRE HARNESS для Polaris SCRAMBLER 850 MD [A15SVA85HD] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    2412801 HARNESS, MAIN (INCL. 1-6,9,12-13, ALL KITS, COVER)
    HARNESS, MAIN (INCL. 1-6,9,12-13, ALL KITS, COVER)
  • 1
    4015011 COVER, FUSE BOX
    COVER, FUSE BOX
  • 2
    4011283 RELAY
    RELAY
  • 3
    2434017 FUSE, 20AMP
    FUSE, 20AMP
  • 4
    2434016 FUSE, 10AMP
    FUSE, 10AMP
  • 5
    2411035 DIODE, 6AMP
    DIODE, 6AMP
  • 6
    4012170 COVER, DIAGNOSTIC
    COVER, DIAGNOSTIC
  • 7
    7080138 CABLE TIE
    CABLE TIE
  • 8
    7080492 CABLE TIE
    CABLE TIE
  • 9
    4011372 BREAKER, CIRCUIT, 20 AMP
    BREAKER, CIRCUIT, 20 AMP
  • 10
    4014891 CAP, WINCH CONTACTOR
    CAP, WINCH CONTACTOR
  • 11
    5258624 BRACKET, FUSE BLOCK
    BRACKET, FUSE BLOCK
  • 12
    2202607 KIT, FUSIBLE LINK, .8 MM
    KIT, FUSIBLE LINK, .8 MM
  • 12
    2202670 KIT, FUSIBLE LINK, 1.0 MM
    KIT, FUSIBLE LINK, 1.0 MM
  • 13
    7180716 LABEL, FUSE BOX
    LABEL, FUSE BOX
  • 14
    7081496 CLIP, ROUTING
    CLIP, ROUTING
  • 15
    4014890 CAP, WINCH SWITCH
    CAP, WINCH SWITCH
  • 16
    4014055 MODULE, RESISTOR
    MODULE, RESISTOR
  • 17
    7519145 SCREW (MAIN HARNESS GROUND TO FRAME)
    SCREW (MAIN HARNESS GROUND TO FRAME)
