COOLING SYSTEM для Polaris TRAIL BOSS 330 (A09CA32AA) - 2009 года выпуска
-
№АртикулНазвание
-
11240465 ASM-OIL COOLER,330ASM-OIL COOLER,330
-
27081364 CLAMP-DBL TUBE, .562 VNL COATEDCLAMP-DBL TUBE, .562 VNL COATED
-
37517386 SCREWSCREW
-
47542122 NUT-NYLOKNUT-NYLOK
-
55245416-067 BRKT-OIL COOLER, TOP, BLACKBRKT-OIL COOLER, TOP, BLACK
-
67547069 NUTSERT, HEXNUTSERT, HEX
-
77512232 BOLTBOLT
-
87517659 SCREWSCREW
-
92410534 ASM-FAN MOTORASM-FAN MOTOR
-
107670111 CLIP, UCLIP, U
-
115433353 SHROUD, FANSHROUD, FAN
-
124010934 THERMISTERTHERMISTER
-
137558301 WASHER, FLATWASHER, FLAT
-
147512247 BOLTBOLT
-
155413650 HOSE-COOLER,THREADED 90°HOSE-COOLER,THREADED 90°
-
177081334 STRAP-TREE MOUNT CABLE TIESTRAP-TREE MOUNT CABLE TIE
