FUEL TANK для Polaris SPORTSMAN 500 HO (A09MH50AZ) (RED) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    2520926 ASM-FUEL TANK,500HO,7 LAYER (INCL. SENDING UNIT)
    ASM-FUEL TANK,500HO,7 LAYER (INCL. SENDING UNIT)
  • 2
    5247184 BRKT-FUEL COVER MT LEFT HAND,PLTD
    BRKT-FUEL COVER MT LEFT HAND,PLTD
  • 2
    5247185 BRKT-FUEL COVER MT RIGHT HAND,PLTD
    BRKT-FUEL COVER MT RIGHT HAND,PLTD
  • 3
    5812265 SEAL-FOAM,12 IN
    SEAL-FOAM,12 IN
  • 4
    7515179 SCREW
    SCREW
  • 5
    5813282 FOIL-FUEL TANK,SIDE,SPORTSMAN
    FOIL-FUEL TANK,SIDE,SPORTSMAN
  • 6
    5813218 FOIL-FUEL TANK,SPORTSMAN
    FOIL-FUEL TANK,SPORTSMAN
  • 7
    7080492 CABLE TIE,11 INCH
    CABLE TIE,11 INCH
  • 8
    5812123 GASKET
    GASKET
  • 9
    5433687 CAP,GAS TANK
    CAP,GAS TANK
  • 10
    8360009-600 LINE,FUEL,1/8 ID,600 CM.
    LINE,FUEL,1/8 ID,600 CM.
