CARBURETOR MOUNTING W/FUEL LINES для Polaris SPORTSMAN 500 HO (A09MH50AZ) (RED) - 2009 года выпуска
-
№АртикулНазвание
-
18450003-1525 LINE,FUEL,1/4 ID(1525 CM.)LINE,FUEL,1/4 ID(1525 CM.)
-
25247155 STRAP-CARB MNT,PLATEDSTRAP-CARB MNT,PLATED
-
33085698 ASM.,SCREW AND WASHERASM.,SCREW AND WASHER
-
47542153 NUT,NYLOK,FLANGEDNUT,NYLOK,FLANGED
-
57052248 VALVE-FUEL,PLASTIC,INLINE 1/4''VALVE-FUEL,PLASTIC,INLINE 1/4''
-
63110050 MOUNT,CARBURETORMOUNT,CARBURETOR
-
77542143 INSERT,INSERT,
-
88360009-600 LINE,FUEL,1/8 ID,600 CM.LINE,FUEL,1/8 ID,600 CM.
-
97051011 VALVE,CHECKVALVE,CHECK
-
107080003 CLAMP,HOSECLAMP,HOSE
-
118450117-250 FUEL HOSE-250 CMFUEL HOSE-250 CM
-
122530009 FILTER,SMALL,IN-LINE,FILTER,SMALL,IN-LINE,
-
138450040-600 LINE FUEL,1/4 ID(600 CM.)LINE FUEL,1/4 ID(600 CM.)
-
147546601 NUT, NYLOKNUT, NYLOK
-
153088070 ASM.,FUEL PUMPASM.,FUEL PUMP
-
167080534 CLAMP,HOSECLAMP,HOSE
