GEARCASE MOUNTING для Polaris SCRAMBLER 400 4X4 (A02BG38CA) - 2002 года выпуска
-
№АртикулНазвание
-
17517632 SCREWSCREW
-
25132046 MOUNT-TRANSMISSION,REAR,MACHMOUNT-TRANSMISSION,REAR,MACH
-
37547089 NUT-3/8-16 FLG LOCK-YNUT-3/8-16 FLG LOCK-Y
-
47512492 SCREWSCREW
-
57555806 WASHERWASHER
-
67517642 SCREWSCREW
-
73221041 SPROCKET (13 TEETH) SPLINEDSPROCKET (13 TEETH) SPLINED
-
87710434 RING,SNAPRING,SNAP
-
95211065 SHIM,.010,GEARCASE (.010)SHIM,.010,GEARCASE (.010)
-
95210764 SPACER, (.020)SPACER, (.020)
-
95211517 SHIM,(.030) (.030)SHIM,(.030) (.030)
-
107517646 SCREWSCREW
