SUSPENSION - FRONT A - ARM W/ TIE RODS для Polaris WORKER 500 (A01CH50EB) - 2001 года выпуска`
-
№АртикулНазвание
-
17542403 NUT LOCKNUT LOCK
-
21820805 TIE, ROD, ASSY (1/2-20X13.4)TIE, ROD, ASSY (1/2-20X13.4)
-
35411291 SEAL, BOOT, ROD END (1/2 IN)SEAL, BOOT, ROD END (1/2 IN)
-
47061034 ROD END (RIGHT)ROD END (RIGHT)
-
57542711 NUT, JAMNUT, JAM
-
65020926 ROD, TIEROD, TIE
-
77547028 NUT, JAM (LEFT)NUT, JAM (LEFT)
-
87517674 BOLT, WASHER HEADBOLT, WASHER HEAD
-
97061054 ROD, END (10MM) (1/2-20) (LEFT)ROD, END (10MM) (1/2-20) (LEFT)
-
105411920 BOOT, SEAL, ROD END (10MM)BOOT, SEAL, ROD END (10MM)
-
117556099 WASHERWASHER
-
127546904 NUT, CASTLENUT, CASTLE
-
137661203 PIN COTTERPIN COTTER
-
147080927 BALL, JOINTBALL, JOINT
-
155211121 BRKT, BALL JOINTBRKT, BALL JOINT
-
167512284 BOLT, SOCKETBOLT, SOCKET
-
175410548 BOOT, RUBBERBOOT, RUBBER
-
187542438 NUT, CASTLENUT, CASTLE
-
195431837 SHIELD, COVER (LEFT/BLACK)SHIELD, COVER (LEFT/BLACK)
-
195431838 SHIELD, COVER (RIGHT/BLACK)SHIELD, COVER (RIGHT/BLACK)
-
207512084 SCREWSCREW
-
215433066 BUSHING, A-ARM LONG (BLACK)BUSHING, A-ARM LONG (BLACK)
-
225020677 BUSHING, A-ARM SPACERBUSHING, A-ARM SPACER
-
235020681 SHAFT, A-ARM (4X4)SHAFT, A-ARM (4X4)
-
242201607 A-FRAME, KIT (1541448) (LEFT)A-FRAME, KIT (1541448) (LEFT)
-
242201608 A-FRAME, KIT (1541449) (RIGHT)A-FRAME, KIT (1541449) (RIGHT)
-
257080433 ZERK, FITTING, THREADEDZERK, FITTING, THREADED
-
277512492 SCREWSCREW
-
287552603 WASHERWASHER
-
297515415 BOLTBOLT
