AIR BOX ASSY. для Polaris SPORTSMAN 90 (A01FA09CA) - 2001 года выпуска`
-
№АртикулНазвание
-
10450066 BOLT, HEXAGON WASHERBOLT, HEXAGON WASHER
-
20450065 MANIFOLD, INTAKEMANIFOLD, INTAKE
-
30450067 CLAMP, HOSE, INTAKE MANIFOLDCLAMP, HOSE, INTAKE MANIFOLD
-
40450068 CLIPCLIP
-
50450075 JOINT, AIR CLEANERJOINT, AIR CLEANER
-
60450071 CAP, CASE AIR CLEANERCAP, CASE AIR CLEANER
-
70450076 SCREW, TAPPINGSCREW, TAPPING
-
80450069 CLEANER, AIR ASSY. (INCL. 5,6,7,9,10,13,14,15)CLEANER, AIR ASSY. (INCL. 5,6,7,9,10,13,14,15)
-
90450074 SEALSEAL
-
100450073 ELEMENT, AIR CLEANERELEMENT, AIR CLEANER
-
110450039 BOLT, SOCKETBOLT, SOCKET
-
120450034 WASHER, PLAINWASHER, PLAIN
-
130450079 GROMMETGROMMET
-
140450070 CASE, AIR CLEANERCASE, AIR CLEANER
-
150450072 PIPE, GUIDE, CLEANERPIPE, GUIDE, CLEANER
-
160450064 GASKET, REEDGASKET, REED
-
170450063 REED VALVE ASSY.REED VALVE ASSY.
