AIR BOX ASSY. для Polaris SCRAMBLER 50 (A01EA05CA) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    0450066 BOLT, HEX WASHER
    BOLT, HEX WASHER
  • 2
    0450065 MANIFOLD, INTAKE
    MANIFOLD, INTAKE
  • 3
    0450067 CLAMP, HOSE INTAKE MANIFOLD
    CLAMP, HOSE INTAKE MANIFOLD
  • 4
    0450068 CLIP
    CLIP
  • 5
    0450075 JOINT, AIR CLEANER
    JOINT, AIR CLEANER
  • 6
    0450071 CAP, CASE AIR CLEANER
    CAP, CASE AIR CLEANER
  • 7
    0450076 SCREW, TAPPING
    SCREW, TAPPING
  • 8
    0450069 CLEANER, AIR (INCL. 5,6,7,9,10,13,14,15)
    CLEANER, AIR (INCL. 5,6,7,9,10,13,14,15)
  • 9
    0450074 SEAL
    SEAL
  • 10
    0450073 ELEMENT, AIR CLEANER
    ELEMENT, AIR CLEANER
  • 11
    0450039 BOLT, SOCKET
    BOLT, SOCKET
  • 12
    0450034 WASHER, PLAIN
    WASHER, PLAIN
  • 13
    0450079 GROMMET
    GROMMET
  • 14
    0450070 CASE, AIR CLEANER
    CASE, AIR CLEANER
  • 15
    0450072 PIPE, GUIDE CLEANER
    PIPE, GUIDE CLEANER
  • 16
    0450064 GASKET, REED
    GASKET, REED
  • 17
    0450062 REED VALVE, ASSY.
    REED VALVE, ASSY.
