Induction Manifold and Reed Block для Mercury - 65 JET 0G760300 THRU 0T979999

  • №
    Артикул
    Название
  • 1
    42878A2 COVER/PLATE KIT, Exhaust
    COVER/PLATE KIT, Exhaust
  • 2
    NSS NOT SOLD SEPARATE, Baffle Plate
    NOT SOLD SEPARATE, Baffle Plate
  • 3
    27-43004009 GASKET
    GASKET
  • 4
    10-82127335 SCREW, (M8 x 35 MM)
    SCREW, (M8 x 35 MM)
  • 5
    22-996642 FITTING, Elbow 90 Degree (.125-27 x .250) Nylon
    FITTING, Elbow 90 Degree (.125-27 x .250) Nylon
  • 6
    27-430075 GASKET
    GASKET
  • 7
    42881A1 SHIFT RAIL ASSEMBLY
    SHIFT RAIL ASSEMBLY
  • 8
    14-42981 TAB WASHER
    TAB WASHER
  • 9
    10-40001134 SCREW, (M8 x 25)
    SCREW, (M8 x 25)
  • 10
    988851 SLIDE
    SLIDE
  • 11
    11-401386 NUT, (M6) Stainless Steel
    NUT, (M6) Stainless Steel
  • 12
    12-35459 WASHER
    WASHER
  • 13
    11-401386 NUT, (M6) Stainless Steel
    NUT, (M6) Stainless Steel
  • 14
    1169-858552T2 END CAP ASSEMBLY, Lower
    SN# SN- USA 0T758474 & Below
    END CAP ASSEMBLY, Lower
    SN# SN- USA 0T758474 & Below
  • 14
    1169-858552T2 CAP ASSEMBLY, Lower End
    SN# SN- USA 0T758475 & Up
    CAP ASSEMBLY, Lower End
    SN# SN- USA 0T758475 & Up
  • 15
    21-426585 CHECK VALVE
    CHECK VALVE
  • 16
    26-41953 SEAL
    SN# SN- USA 0T758474 & Below
    SEAL
    SN# SN- USA 0T758474 & Below
  • 16
    26-419533 SEAL, Oil
    SN# SN- USA 0T758475 & Up
    SEAL, Oil
    SN# SN- USA 0T758475 & Up
  • 17
    25-89224 O-RING
    O-RING
  • 18
    10-4010825 SCREW, (M10 x 25) Hex Flange - Stainless Steel
    SCREW, (M10 x 25) Hex Flange - Stainless Steel
  • 19
    42963A11 REED BLOCK ASSEMBLY
    REED BLOCK ASSEMBLY
  • 20
    NSS NOT SOLD SEPARATE, Dowel Pin
    NOT SOLD SEPARATE, Dowel Pin
  • 21
    27-139376 GASKET
    GASKET
  • 22
    34-43018A1 REED SET
    REED SET
  • 23
    14-429821 TAB WASHER
    TAB WASHER
  • 24
    42924 RETAINER
    RETAINER
  • 25
    10-88421471 SCREW, (M6 x 16)
    SCREW, (M6 x 16)
  • 26
    8M0039350 BRACKET
    (Non Oil Injection)
    BRACKET
    (Non Oil Injection)
  • 26
    827514 BRACKET
    (Oil Injection)
    BRACKET
    (Oil Injection)
  • 27
    12-49221 WASHER, (.187 x .500 x .062) Neoprene
    WASHER, (.187 x .500 x .062) Neoprene
  • 28
    11-816872 WING NUT
    WING NUT
  • 29
    16-8161949 STUD, (M6 x 44)
    STUD, (M6 x 44)
  • 30
    884296T MANIFOLD, Induction
    MANIFOLD, Induction
  • 31
    10-82127335 SCREW, (M8 x 35 MM)
    SCREW, (M8 x 35 MM)
  • 32
    10-81742740 SCREW, (M8 x 40)
    SCREW, (M8 x 40)
  • 33
    16-824470 STUD, (M8 x 1.25)
    STUD, (M8 x 1.25)
  • 34
    10-40001167 SCREW, (M8 x 110) (#3 Cylinder)
    SCREW, (M8 x 110) (#3 Cylinder)
  • 35
    32-8M0108349 TUBING, (.312) (70.00 Inches Bulk) (Cut to 4.00 Inches Length)
    TUBING, (.312) (70.00 Inches Bulk) (Cut to 4.00 Inches Length)
  • 36
    22-432881 TEE FITTING
    (Electric)
    TEE FITTING
    (Electric)
  • 36
    22-8585531 CONNECTOR
    (Manual)
    CONNECTOR
    (Manual)
  • 37
    22-996642 FITTING, Elbow 90 Degree (.125-27 x .250) Nylon
    FITTING, Elbow 90 Degree (.125-27 x .250) Nylon
  • 38
    54-816311T TIE STRAP, (8.00 Inches)
    TIE STRAP, (8.00 Inches)
  • 39
    37-856985A8 DECAL, EPA Label Information
    (1999)
    DECAL, EPA Label Information
    (1999)
  • 39
    37-804666A00 DECAL, EPA Label Information
    (2000)
    DECAL, EPA Label Information
    (2000)
  • 39
    37-804666A01 DECAL, EPA Label Information
    (2001)
    DECAL, EPA Label Information
    (2001)
  • 39
    37-804666A02 DECAL, EPA Label Information
    (2002)
    DECAL, EPA Label Information
    (2002)
  • 39
    37-804666A03 DECAL, EPA Label Information
    (2003)
    DECAL, EPA Label Information
    (2003)
  • 39
    37-804666A04 DECAL, EPA Label Information
    (2004)
    DECAL, EPA Label Information
    (2004)
  • -
    27-43004A99 GASKET SET, Powerhead
    GASKET SET, Powerhead
  • -
    898208A02 POWERHEAD ASSEMBLY
    (Non Oil Injection)
    POWERHEAD ASSEMBLY
    (Non Oil Injection)
  • -
    809837T97 POWERHEAD ASSEMBLY
    (Oil Injection)
    POWERHEAD ASSEMBLY
    (Oil Injection)
