INTAKE MANIFOLD AND OIL PUMP для Mercruiser - 225 (2 BBL.) GM 327 V-8 1967-1969 2278647 THRU 2694014

  • №
    Артикул
    Название
  • 1
    33224 OIL FILLER CAP ASSEMBLY
    OIL FILLER CAP ASSEMBLY
  • 2
    32-49601 TUBE ASSEMBLY, OIL FILLER CAP (STERN DRIVE)
    TUBE ASSEMBLY, OIL FILLER CAP (STERN DRIVE)
  • 2
    32-47733 TUBE ASSEMBLY, OIL FILLER CAP (INBOARD)
    TUBE ASSEMBLY, OIL FILLER CAP (INBOARD)
  • 3
    52227 INTAKE MANIFOLD
    INTAKE MANIFOLD
  • 4
    10-26487 BOLT, INTAKE MANIFOLD TO CYLINDER BLOCK (1 1/8")
    BOLT, INTAKE MANIFOLD TO CYLINDER BLOCK (1 1/8")
  • 4
    16-48337 STUD, INTAKE MANIFOLD TO CYLINDER BLOCK
    STUD, INTAKE MANIFOLD TO CYLINDER BLOCK
  • 5
    22-48336 PLUG, PIPE-INTAKE MANIFOLD
    PLUG, PIPE-INTAKE MANIFOLD
  • 6
    54-49647 EYE, LIFTING
    EYE, LIFTING
  • 6
    54-47512 EYE, LIFTING
    EYE, LIFTING
  • 7
    10-34354 SCREW, LIFTING EYE ATTACHING (1 1/2")
    SCREW, LIFTING EYE ATTACHING (1 1/2")
  • 8
    13-35048 LOCKWASHER, LIFTING EYE SCREW
    LOCKWASHER, LIFTING EYE SCREW
  • 9
    27-52201 GASKET SET, INTAKE MANIFOLD
    GASKET SET, INTAKE MANIFOLD
  • 10
    35357 VENTILATOR ASSEMBLY, CYLINDER BLOCK
    VENTILATOR ASSEMBLY, CYLINDER BLOCK
  • 11
    10-8M0040582 SCREW, VENTILATOR TO CYLINDER BLOCK (7/16")
    SCREW, VENTILATOR TO CYLINDER BLOCK (7/16")
  • 12
    46-8M0113734 WATER PUMP ASSEMBLY
    WATER PUMP ASSEMBLY
  • 13
    27-34897 GASKET, WATER PUMP MOUNTING
    GASKET, WATER PUMP MOUNTING
  • 14
    27-35380 GASKET, WATER PUMP BACKING PLATE
    GASKET, WATER PUMP BACKING PLATE
  • 15
    22-48336 PLUG, PIPE-WATER PUMP
    PLUG, PIPE-WATER PUMP
  • 16
    10-32132 BOLT, WATER PUMP TO CYLINDER BLOCK (1 3/4")
    BOLT, WATER PUMP TO CYLINDER BLOCK (1 3/4")
  • 16
    10-47688 BOLT, WATER PUMP TO CYLINDER BLOCK (2 3/4")
    BOLT, WATER PUMP TO CYLINDER BLOCK (2 3/4")
  • 16
    10-35344 BOLT, WATER PUMP TO CYLINDER BLOCK (1 5/8")
    BOLT, WATER PUMP TO CYLINDER BLOCK (1 5/8")
  • 16
    16-8M0076418 STUD, WATER PUMP TO CYLINDER BLOCK
    STUD, WATER PUMP TO CYLINDER BLOCK
  • 17
    33864 PULLEY, WATER PUMP
    PULLEY, WATER PUMP
  • 18
    47282 SUPPORT, WATER PUMP PULLEY
    SUPPORT, WATER PUMP PULLEY
  • --
    37242 REINFORCEMENT, WATER PUMP PULLEY
    REINFORCEMENT, WATER PUMP PULLEY
  • 19
    10-47277 SCREW, PULLEY AND SUPPORT TO WATER PUMP (3/4")
    SCREW, PULLEY AND SUPPORT TO WATER PUMP (3/4")
  • 20
    13-39107 LOCKWASHER, WATER PUMP PULLEY SCREW
    LOCKWASHER, WATER PUMP PULLEY SCREW
  • 21
    48331 BALANCER, HARMONIC-CRANKSHAFT
    BALANCER, HARMONIC-CRANKSHAFT
  • 22
    33863T PULLEY, HARMONIC BALANCER
    PULLEY, HARMONIC BALANCER
  • 23
    10-34281 BOLT, PULLEY AND HARMONIC BALANCER TO CRANKSHAFT (2")
    BOLT, PULLEY AND HARMONIC BALANCER TO CRANKSHAFT (2")
  • 24
    13-39131 LOCKWASHER, PULLEY AND HARMONIC BALANCER BOLT
    LOCKWASHER, PULLEY AND HARMONIC BALANCER BOLT
  • 25
    12-35332001 WASHER, PULLEY AND HARMONIC BALANCER BOLT
    WASHER, PULLEY AND HARMONIC BALANCER BOLT
  • 26
    10-34352 BOLT, CRANKSHAFT PULLEY TO HARMONIC BALANCER
    BOLT, CRANKSHAFT PULLEY TO HARMONIC BALANCER
  • 27
    13-35048 LOCKWASHER, CRANKSHAFT PULLEY BOLT
    LOCKWASHER, CRANKSHAFT PULLEY BOLT
  • 28
    57-48120Q1 BELT, ALTERNATOR DRIVE (46")
    BELT, ALTERNATOR DRIVE (46")
  • 29
    37645A1 ADAPTOR ASSEMBLY, VENT
    ADAPTOR ASSEMBLY, VENT
  • 30
    27-34565 GASKET, VENT ADAPTOR
    GASKET, VENT ADAPTOR
  • 31
    10-39245 SCREW, VENT ADAPTOR TO CYLINDER BLOCK
    SCREW, VENT ADAPTOR TO CYLINDER BLOCK
  • 32
    12-37507 WASHER, VENT ADAPTOR SCREW
    WASHER, VENT ADAPTOR SCREW
  • 33
    27-35593 GASKET, VENT ADAPTOR SCREW
    GASKET, VENT ADAPTOR SCREW
  • 34
    841-2350 CYLINDER BLOCK ASSEMBLY
    SEE G2 FOR BREAKDOWN
    CYLINDER BLOCK ASSEMBLY
    SEE G2 FOR BREAKDOWN
  • 35
    398-3565 SUPPORT, SPARK PLUG LEAD WIRE
    SUPPORT, SPARK PLUG LEAD WIRE
  • 36
    10-8M0040582 SCREW, LEAD WIRE SUPPORT TO CYLINDER BLOCK (1/2")
    SCREW, LEAD WIRE SUPPORT TO CYLINDER BLOCK (1/2")
  • 37
    13-35367 LOCKWASHER, LEAD WIRE SUPPORT SCREW
    LOCKWASHER, LEAD WIRE SUPPORT SCREW
  • 38
    36184 SHAFT, OIL PUMP TO DISTRIBUTOR
    SHAFT, OIL PUMP TO DISTRIBUTOR
  • 39
    23-36183 RETAINER, OIL PUMP SHAFT
    RETAINER, OIL PUMP SHAFT
  • 40
    17617 OIL PUMP ASSEMBLY
    OIL PUMP ASSEMBLY
  • 41
    10-48333 BOLT, OIL PUMP TO CYLINDER BLOCK (2")
    BOLT, OIL PUMP TO CYLINDER BLOCK (2")
  • 42
    35354 SEREEN ASSEMBLY, OIL PUMP
    SEREEN ASSEMBLY, OIL PUMP
  • 43
    33169 FILTER VALVE ASSEMBLY
    FILTER VALVE ASSEMBLY
  • 44
    10-24878 SCREW, FILTER VALVE TO CYLINDER BLOCK (1 1/4")
    SCREW, FILTER VALVE TO CYLINDER BLOCK (1 1/4")
  • 45
    25-33756 "O" RING, OIL FILTER TO FILTER VALVE
    "O" RING, OIL FILTER TO FILTER VALVE
  • 46
    33168 OIL FILTER ASSEMBLY
    OIL FILTER ASSEMBLY
  • 47
    33987 ELEMENT, OIL FILTER
    ELEMENT, OIL FILTER
  • 48
    35315 COVER ASSEMBLY, CRANKCASE FRONT END (STANDARD ROTATION)
    COVER ASSEMBLY, CRANKCASE FRONT END (STANDARD ROTATION)
  • 48
    48339 COVER ASSEMBLY, CRANKCASE FRONT END (OPPOSITE ROTATION)
    COVER ASSEMBLY, CRANKCASE FRONT END (OPPOSITE ROTATION)
  • 49
    26-97335 OIL SEAL, CRANKCASE FRONT END COVER
    OIL SEAL, CRANKCASE FRONT END COVER
  • 50
    27-14250 GASKET, CRANKCASE FRONT END COVER
    GASKET, CRANKCASE FRONT END COVER
  • 51
    10-8M0040582 SCREW, CRANKCASE FRONT END COVER TO CYLINDER BLOCK (7/16")
    SCREW, CRANKCASE FRONT END COVER TO CYLINDER BLOCK (7/16")
