Cylinder Head для Mariner - 30 EFI (3 CYL.)(4-STROKE) 0T409000 THRU 1B226999

  • №
    Артикул
    Название
  • -
    893504T01 CYLINDER HEAD ASSEMBLY
    CYLINDER HEAD ASSEMBLY
  • 1
    893504T CYLINDER HEAD
    CYLINDER HEAD
  • 2
    858266 GUIDE
    GUIDE
  • 3
    10-4000325 SCREW, (M6 x 8)
    SCREW, (M6 x 8)
  • 4
    12-859768 WASHER
    WASHER
  • 5
    26-893549 SEAL, Oil
    SEAL, Oil
  • 6
    22-875209 PIPE PLUG
    PIPE PLUG
  • 7
    25-893898 O-RING
    O-RING
  • 8
    893693A04 COVER
    COVER
  • 9
    22-825054 BREATHER PIPE
    BREATHER PIPE
  • 10
    855236 PLATE, Baffle
    PLATE, Baffle
  • 11
    10-4005685 SCREW, (M4 x 10)
    SCREW, (M4 x 10)
  • 12
    NSS NOT SOLD SEPARATE, Decal-Servicing Referral
    NOT SOLD SEPARATE, Decal-Servicing Referral
  • 13
    NSS NOT SOLD SEPARATE, Decal-Engine Oil/Valve Clearance
    NOT SOLD SEPARATE, Decal-Engine Oil/Valve Clearance
  • 14
    27-8M0118180 GASKET
    GASKET
  • 15
    10-8M4503518 SCREW, (M6 x 20) Stainless Steel
    SCREW, (M6 x 20) Stainless Steel
  • 16
    10-82503395 SCREW, (M9 x 95)
    SCREW, (M9 x 95)
  • 17
    10-893745025 SCREW, (M6 x 25)
    SCREW, (M6 x 25)
  • 18
    22-629101 FITTING, Elbow - 90 Degree (.125-27)
    FITTING, Elbow - 90 Degree (.125-27)
  • 19
    830294T3 BRACKET
    (HANDLE)
    BRACKET
    (HANDLE)
  • 20
    10-8M4503518 SCREW, (M6 x 20) Stainless Steel
    (HANDLE)
    SCREW, (M6 x 20) Stainless Steel
    (HANDLE)
  • 21
    859578A1 PLUG ASSEMBLY, Oil
    PLUG ASSEMBLY, Oil
  • 22
    25-90196 O-RING, (.921 x .139)
    O-RING, (.921 x .139)
  • 23
    NSS NOT SOLD SEPARATE, Decal-HP-ID
    30
    NOT SOLD SEPARATE, Decal-HP-ID
    30
  • 23
    NSS NOT SOLD SEPARATE, Decal-HP-ID
    40
    NOT SOLD SEPARATE, Decal-HP-ID
    40
  • 24
    17-825010 PIN, Dowel
    PIN, Dowel
  • -
    61-803017T01 POWERHEAD ASSEMBLY
    POWERHEAD ASSEMBLY
  • -
    27-859352A02 GASKET SET
    GASKET SET
