Steering Helm Kit-Standard(892557A02, 892380A02, 892558A02) для Mariner - 250 VERADO (4-STROKE)(6 CYL.) 0P520553 THRU 2B144122

  • №
    Артикул
    Название
  • -
    892557A02 STEERING HELM KIT, Standard (32 cc)
    STEERING HELM KIT, Standard (32 cc)
  • -
    8M0137445 STEERING HELM KIT, Standard (40 cc)
    STEERING HELM KIT, Standard (40 cc)
  • -
    8M0137449 STEERING HELM KIT, Standard (50 cc)
    STEERING HELM KIT, Standard (50 cc)
  • 1
    8M0137438 HELM, Standard (32 cc)
    HELM, Standard (32 cc)
  • 1
    8M0137444 HELM, Standard (40 cc)
    HELM, Standard (40 cc)
  • 1
    8M0137448 HELM, Standard (50 cc)
    HELM, Standard (50 cc)
  • 2
    25-627021 O-RING, (.301 x .070)
    O-RING, (.301 x .070)
  • 3
    25-48171 O-RING, (.364. x .070)
    O-RING, (.364. x .070)
  • 4
    28-893394 KEY, With Lock Tab (6.35 mm)
    KEY, With Lock Tab (6.35 mm)
  • 5
    10-4008875 SCREW, (M6 x 75)
    SCREW, (M6 x 75)
  • 5
    10-4008850 SCREW, (M6 x 50)
    SCREW, (M6 x 50)
  • 6
    11-826709121 NUT, (.625-18) Stainless Steel
    NUT, (.625-18) Stainless Steel
  • 7
    892328T COVER, Helm
    COVER, Helm
  • 8
    10-896842 SCREW, (M6 x 14)
    SCREW, (M6 x 14)
  • 9
    892327 PLATE, Helm Backing
    (892557A02)
    PLATE, Helm Backing
    (892557A02)
  • 9
    892327 PLATE, Helm Backing
    (892380A02)
    PLATE, Helm Backing
    (892380A02)
  • 9
    892327 PLATE, Helm Backing
    (892558A02)
    PLATE, Helm Backing
    (892558A02)
  • 10
    11-401196 NUT, (M6)
    NUT, (M6)
