FRONT FORK TRIPLE CLAMP для Ktm 85 SX 19/16 - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    05187M0501 FORK WP
    FORK WP
  • 2
    59030029000 HH NUT M20X1,5 WS=27 RIGHT
    HH NUT M20X1,5 WS=27 RIGHT
  • 3
    47101034114 TOP TRIPLE CLAMP
    TOP TRIPLE CLAMP
  • 4
    47101032114 BOTTOM TRIPLE CLAMP CPL.
    BOTTOM TRIPLE CLAMP CPL.
  • 5
    49001081000 TAPERED ROLLER BEARING 32004X
    TAPERED ROLLER BEARING 32004X
  • 6
    0025080256 HH COLLAR SCREW M8X25 TX40
    HH COLLAR SCREW M8X25 TX40
  • 7
    77201038000 HANDLEBAR CLAMP 28MM
    HANDLEBAR CLAMP 28MM
  • 8
    0032100356S AH-COLLAR SCREW M10X35 ISA45
    AH-COLLAR SCREW M10X35 ISA45
  • 9
    59401039037 HANDLEB .SUPP . D=28MM H=37MM
    HANDLEB .SUPP . D=28MM H=37MM
  • 10
    0025080306 HH COLLAR SCREW M8X30 TX40
    HH COLLAR SCREW M8X30 TX40
  • 11
    49001086000 COVERING CAP
    COVERING CAP
  • 12
    0770049025 O-RING 49,00X2,50 NBR
    O-RING 49,00X2,50 NBR
  • 13
    46001086000 PROTECTION RING 20,1X39X5
    PROTECTION RING 20,1X39X5
  • 15
    0025080206 HH COLLAR SCREW M8X20 TX40
    HH COLLAR SCREW M8X20 TX40
  • 16
    0017060206 SCREW F . PLASTIC K60X20AL SW6
    SCREW F . PLASTIC K60X20AL SW6
  • 17
    7800108500028 CLAMP F . SPEED. CABLE D=6MM
    CLAMP F . SPEED. CABLE D=6MM
  • 18
    59001092050 SPECIAL SCREW M6X12,5 WS=8
    SPECIAL SCREW M6X12,5 WS=8
  • 97
    4710109400028 FORK PROTECTOR SET (WHITE)
    FORK PROTECTOR SET (WHITE)
  • 98
    00050000931 STEERING HEAD REP . KIT MINI
    STEERING HEAD REP . KIT MINI
  • 99
    00050000921 HANDLEBAR SUPPORT KIT D28/H37
    HANDLEBAR SUPPORT KIT D28/H37
