FRONT FORK DISASSEMBLED для Ktm 200 XC - 2014 года выпуска

  • №
    Артикул
    Название
  • 3
    48600812S ADJUSTING KNOB + SCREW
    ADJUSTING KNOB + SCREW
  • 4
    48600481 VENT SCREW M4X8
    VENT SCREW M4X8
  • 5
    48600046 O-RING NBR 3X1,5
    O-RING NBR 3X1,5
  • 6
    46810340 O-RING NBR 45X2
    O-RING NBR 45X2
  • 12
    48600736 OUTER TUBE L577 D54/60MM 2L
    OUTER TUBE L577 D54/60MM 2L
  • 13
    48600698 FORK PROTECTION RING 08
    FORK PROTECTION RING 08
  • 15
    48601009 GUIDING BUSH 48X52X12 R11
    GUIDING BUSH 48X52X12 R11
  • 16
    48600013 SUPPORT RING 50 X 57,6 X 1,5
    SUPPORT RING 50 X 57,6 X 1,5
  • 17
    48600969 OIL SEAL RING D48 SKF
    OIL SEAL RING D48 SKF
  • 18
    48600070 LOCK WASHER SB58
    LOCK WASHER SB58
  • 19
    48600968 DUST SEAL DL D48 SKF
    DUST SEAL DL D48 SKF
  • 22
    48601008 GUIDING BUSH 47X49X20 R11
    GUIDING BUSH 47X49X20 R11
  • 24
    48600557S HYDR.STOP L=200 D=31,9 CPL.
    HYDR.STOP L=200 D=31,9 CPL.
  • 30
    48600559 ADJUSTING TUBE L=520 07
    ADJUSTING TUBE L=520 07
  • 31
    48600568 PISTON ROD D=12 L=554 ALU
    PISTON ROD D=12 L=554 ALU
  • 33
    48600277 ADJUSTER NEEDLE
    ADJUSTER NEEDLE
  • 34
    48600298 O-RING 2X1,5 NBR
    O-RING 2X1,5 NBR
  • 35
    48600444 REBOUND SPRING C=4N/MM
    REBOUND SPRING C=4N/MM
  • 36
    48600113 WASHER 32X42X2,5
    WASHER 32X42X2,5
  • 38
    91410012S SPRING 3,8N/MM SET D=4,9MM
    SPRING 3,8N/MM SET D=4,9MM
  • 38
    91410013S SPRING 4,0N/MM SET D=5,0MM
    SPRING 4,0N/MM SET D=5,0MM
  • 38
    91410014S SPRING 4,2N/MM SET D=5,0MM
    SPRING 4,2N/MM SET D=5,0MM
  • 38
    91410015S SPRING 4,4N/MM SET D=5,1MM
    SPRING 4,4N/MM SET D=5,1MM
  • 38
    91410016S SPRING 4,6N/MM SET
    SPRING 4,6N/MM SET
  • 39
    48600021 INTERM. RING 26,2 X 43 X 3
    INTERM. RING 26,2 X 43 X 3
  • 40
    48600525 GUIDING BUSH REBOUND SPRING
    GUIDING BUSH REBOUND SPRING
  • 42
    48600830S SCREW SLEEVE M27X0,8
    SCREW SLEEVE M27X0,8
  • 43
    48600299 O-RING 6X1,2 NBR
    O-RING 6X1,2 NBR
  • 44
    48600511 REBOUND SPRING L=32 C=17
    REBOUND SPRING L=32 C=17
  • 45
    48600576 PISTON ROD REBOUND
    PISTON ROD REBOUND
  • 47
    48600382 SHUTTLE VALVE SPRING C=0,4
    SHUTTLE VALVE SPRING C=0,4
  • 51
    48600455 PISTON RING 5X1X68
    PISTON RING 5X1X68
  • 52
    48600575 PISTON REBOUND SX 2007
    PISTON REBOUND SX 2007
  • 55
    40540486 NUT M6X0,5 REBOUND
    NUT M6X0,5 REBOUND
  • 57
    48600764 ADAPTER SLEEVE D23/D28
    ADAPTER SLEEVE D23/D28
  • 58
    48600763 PIPE D23/L350 09
    PIPE D23/L350 09
  • 59
    48600048 O-RING NBR 46 X 2
    O-RING NBR 46 X 2
  • 60
    48600860SA AXLE CLAMP L/S + TUBE CPL.
    AXLE CLAMP L/S + TUBE CPL.
  • 61
    48600861S1 AXLE CLAMP R/S + TUBE CPL.
    AXLE CLAMP R/S + TUBE CPL.
  • 62
    25080256 HH COLLAR SCREW M8X25 TX40
    HH COLLAR SCREW M8X25 TX40
  • 63
    48600163 CHECK VALVE NUT M6X0,5 D=2
    CHECK VALVE NUT M6X0,5 D=2
  • 64
    48600202 SPRING CHECK VALVE D=0,7
    SPRING CHECK VALVE D=0,7
  • 69
    48600586S TAP COMPRESSION CPL.
    TAP COMPRESSION CPL.
  • 71
    48600047 PISTON COMPRESSION D=27,9
    PISTON COMPRESSION D=27,9
  • 71
    48600047 PISTON COMPRESSION D=27,9
    PISTON COMPRESSION D=27,9
  • 72
    46811499 O-RING NBR 21X2
    O-RING NBR 21X2
  • 73
    35480320 O-RING NBR 24X2
    O-RING NBR 24X2
  • 81
    48600004 COPPER WASHER 29,5X33,5X1
    COPPER WASHER 29,5X33,5X1
  • 82
    48600141 RUBBER CAP D=35MM
    RUBBER CAP D=35MM
  • 83
    48601166S1 FORK OIL SAE4 5L
    FORK OIL SAE4 5L
  • 85
    48600431S2 PRE-LOAD ADJ. M51X1,5 09
    PRE-LOAD ADJ. M51X1,5 09
  • 86
    48600038 SPACER 42X26,5X10
    SPACER 42X26,5X10
  • 86
    48600037 SPACER 42X26,5X5
    SPACER 42X26,5X5
  • 86
    48600036 SPACER 42X26,5X2,5
    SPACER 42X26,5X2,5
  • 86
    48600053 SPACER 42X26,5X1,5
    SPACER 42X26,5X1,5
  • 98
    T511 SILICONE GREASE F.
    SILICONE GREASE F.
  • 99
    R14020 SXS SERVICE KIT
    SXS SERVICE KIT
