COOLING SYSTEM для Ktm 50 SX - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    45235007000 RADIATOR L/S 50 SX
    RADIATOR L/S 50 SX
  • 2
    45235008000 RADIATOR R/S 50 SX
    RADIATOR R/S 50 SX
  • 3
    41001052000 RUBBER SLEEVE D=12MM
    RUBBER SLEEVE D=12MM
  • 4
    45235009000 RADIATOR CAP 1,8 BAR
    RADIATOR CAP 1,8 BAR
  • 5
    45235034000 RAD. PROTECT. L/S 50 SXS
    RAD. PROTECT. L/S 50 SXS
  • 6
    45235035000 RAD. PROTECT. R/S 50 SX
    RAD. PROTECT. R/S 50 SX
  • 7
    54808020000 SPACER BUSHING
    SPACER BUSHING
  • 8
    0024060206 HH COLLAR SCREW M6X20 TX30
    HH COLLAR SCREW M6X20 TX30
  • 20
    45235026000 RADIATOR HOSE AHEAD 50 SX
    RADIATOR HOSE AHEAD 50 SX
  • 21
    45235027000 RADIATOR HOSE BELOW 50 SX
    RADIATOR HOSE BELOW 50 SX
  • 22
    45235025000 PREFORMED HOSE 50SX RAD. L/S
    PREFORMED HOSE 50SX RAD. L/S
  • 23
    45235024000 PREFORMED HOSE 50SX RAD. R/S
    PREFORMED HOSE 50SX RAD. R/S
  • 24
    55007016001 PVC-HOSE 7X10 PER METER
    PVC-HOSE 7X10 PER METER
  • 25
    42013037300 HOSE CLAMP NORMA 12/22
    HOSE CLAMP NORMA 12/22
