FRAME для Ktm 990 SUPERMOTO-R - 2010 года выпуска

-
№АртикулНазвание
-
1*6260300110004 FRAME "FC10" ORANGEFRAME "FC10" ORANGE
-
254403135000 PLASTIC CAP SFL10PLASTIC CAP SFL10
-
36250300500033S ENGINE SUPPORT L/SENGINE SUPPORT L/S
-
46250300600033S ENGINE SUPPORT R/SENGINE SUPPORT R/S
-
50035100249 AH-COLLAR SCREW M10X24 ISA45AH-COLLAR SCREW M10X24 ISA45
-
654310086100 SELF LOCKING NUT M10 CU WS=14SELF LOCKING NUT M10 CU WS=14
-
760003013000 ENGINE BRAC. SCREW M10X172ENGINE BRAC. SCREW M10X172
-
860003014000 ENGINE BRAC. SCREW M10X206ENGINE BRAC. SCREW M10X206
-
960004076100 CHAIN SLIDING BLOCKCHAIN SLIDING BLOCK
-
100017060204 EJOT PT SCREW K60X20 ALU WS=6EJOT PT SCREW K60X20 ALU WS=6
-
1162603005050 COVER ENGINE SUPPORT LEFTCOVER ENGINE SUPPORT LEFT
-
1262603006050 COVER ENGINECOVER ENGINE
-
130019050121 COUNTERSUNK SCREW ISA25 M5X12COUNTERSUNK SCREW ISA25 M5X12
-
1454630044000 COLLAR NUT M10 WS=13COLLAR NUT M10 WS=13
-
1960003044000 BOLT FOR FOOTREST REARBOLT FOR FOOTREST REAR
-
210799060003 TAB WASHER DIN6799-RS 6,0TAB WASHER DIN6799-RS 6,0
-
2260003152000 ENGAGE PANEL FOOTREST L/SENGAGE PANEL FOOTREST L/S
-
2360003052000 ENGAGE PANEL FOOTREST R/SENGAGE PANEL FOOTREST R/S
-
2460003098000 RUBBER SLEEVERUBBER SLEEVE
-
2558403060000 CHAIN ROLL 12X29X22,5CHAIN ROLL 12X29X22,5
-
2658403060065 BUSH CHAIN ROLL 8X12X23BUSH CHAIN ROLL 8X12X23
-
270025080406 HH COLLAR SCREW M8X40 TX40HH COLLAR SCREW M8X40 TX40
-
2836003014000 LOCK WASHER 8MMLOCK WASHER 8MM
-
306260300210033 SUB FRAME SM BLACK MATTSUB FRAME SM BLACK MATT
-
310019100289S COUNTERSUNK SCREW ISA45 M10X28COUNTERSUNK SCREW ISA45 M10X28
-
3260003001051 COLLAR BUSHING 10X15X25X4COLLAR BUSHING 10X15X25X4
-
346250304800033S FOOTREST BRACKET REAR L/SFOOTREST BRACKET REAR L/S
-
356250304900033S FOOTREST BRACKET REAR R/SFOOTREST BRACKET REAR R/S
-
360019080266S COUNTER-SUNK SCREW ISA45 M8X26COUNTER-SUNK SCREW ISA45 M8X26
-
3860003050000 FOOTREST CPL. L/S REARFOOTREST CPL. L/S REAR
-
3960003051000 FOOTREST CPL. R/S REARFOOTREST CPL. R/S REAR
-
4660103088000 PLUG ZK 8/5PLUG ZK 8/5
-
5059003040250 FOOT PEG L/S SILVERFOOT PEG L/S SILVER
-
5159003041250 FOOT PEG R/S SILVERFOOT PEG R/S SILVER
-
5260003040010 FOOTREST RUBBER FRONT L/SFOOTREST RUBBER FRONT L/S
-
5360003041010 FOOTREST RUBBER FRONT R/SFOOTREST RUBBER FRONT R/S
-
5460003044010 CLOSING PANEL FRONT L/S R/SCLOSING PANEL FRONT L/S R/S
-
55985050003 SELF LOCKING NUT DIN0985-M 5SELF LOCKING NUT DIN0985-M 5
-
5654803044000 BOLT FOR FOOT PEDBOLT FOR FOOT PED
-
5754603041000 FOOTREST SPRING L/S & R/SFOOTREST SPRING L/S & R/S
-
58125100003 WASHER DIN0125-A10,5WASHER DIN0125-A10,5
-
590094032253 PIN DIN0094-3,2X25 STEELPIN DIN0094-3,2X25 STEEL
-
6060003095100 CAGE NUT M8CAGE NUT M8
-
6160011038000 CAGE NUT M6 SL K100-1 1,5MMCAGE NUT M6 SL K100-1 1,5MM
-
6254603048000 RANGE CHANGE METAL NUT M8RANGE CHANGE METAL NUT M8
-
6354603048100 RANGE CHANGE METAL NUT M6RANGE CHANGE METAL NUT M6
-
640019100239S COUNTERSUNK SCREW ISA45 M10X23COUNTERSUNK SCREW ISA45 M10X23
-
6561003002080 BLIND RIVET NUT M8 HUC/ROF 5 0BLIND RIVET NUT M8 HUC/ROF 5 0
