AIRBOX для Ktm 990 SUPERMOTO-R - 2010 года выпуска

  • №
    Артикул
    Название
  • 1
    61006002000 AIRBOX COVER 990 DUKE
    AIRBOX COVER 990 DUKE
  • 2
    61006015000 AIR FILTER EFI
    AIR FILTER EFI
  • 3
    60006007000 CONNECTOR FOR SAS LC8
    CONNECTOR FOR SAS LC8
  • 4
    60006007050 GASKET SAS CONNECTOR
    GASKET SAS CONNECTOR
  • 6
    60006040000 INTAKE SNORKEL
    INTAKE SNORKEL
  • 7
    60006004000 AIRBOX FRONT PART LC8
    AIRBOX FRONT PART LC8
  • 8
    60006006000 SPECIAL SCREW K60X35/15
    SPECIAL SCREW K60X35/15
  • 9
    60006003002 AIRBOX COVER L/S R/S
    AIRBOX COVER L/S R/S
  • 10
    60006003050 GASKET F. AIRBOX COVER L/S R/S
    GASKET F. AIRBOX COVER L/S R/S
  • 11
    0017060203 EJOT PT SCREW K60X20 WS=6
    EJOT PT SCREW K60X20 WS=6
  • 12
    61006001000 FILTER BOX LOWER PART
    FILTER BOX LOWER PART
  • 13
    61006003002 AIRBOX COVER R/S EFI
    AIRBOX COVER R/S EFI
  • 14
    61006001030 RUBBER SLEEVE F. THR. CABLE
    RUBBER SLEEVE F. THR. CABLE
  • 15
    61006001020 SAS-BRACKET PANEL
    SAS-BRACKET PANEL
  • 16
    54603048100 RANGE CHANGE METAL NUT M6
    RANGE CHANGE METAL NUT M6
  • 17
    60006001021 DISTANCE RUBBER AIRBOX
    DISTANCE RUBBER AIRBOX
  • 18
    0025060166 HH COLLAR SCREW M6X16 TX30
    HH COLLAR SCREW M6X16 TX30
  • 19
    60036045000 RUBBER SLEEVE AIRBOX
    RUBBER SLEEVE AIRBOX
  • 21
    60006001041 RUBBER SLEEVE FUEL HOSE
    RUBBER SLEEVE FUEL HOSE
  • 23
    57005020001 HOSE 10X14 PER METER
    HOSE 10X14 PER METER
  • 24
    61041080000 AMBIENT-AIR TEMPERATURE SENSOR
    AMBIENT-AIR TEMPERATURE SENSOR
  • 25
    0081500181 SCREW FOR PLASTIC D=5X18
    SCREW FOR PLASTIC D=5X18
