COOLING SYSTEM для Ktm 400 XC-W - 2010 года выпуска

  • №
    Артикул
    Название
  • 7*
    77035007200 RADIATOR L/S 250 SX-F
    RADIATOR L/S 250 SX-F
  • 8
    78035008000 RADIATOR R/S "45556" 08
    RADIATOR R/S "45556" 08
  • 9
    77335016000 RADIATOR CAP SMALL 1,8 BAR
    RADIATOR CAP SMALL 1,8 BAR
  • 19
    77335026000 T-CONNECTOR CPL. ґ07
    T-CONNECTOR CPL. ґ07
  • 20
    10001020000 HOSE CLAMP GEMI 16-27
    HOSE CLAMP GEMI 16-27
  • 21*
    42013037400 HOSE CLAMP NORMA 12/24
    HOSE CLAMP NORMA 12/24
  • 22
    58335099000 HOSE CLAMP GEMI 10-16
    HOSE CLAMP GEMI 10-16
  • 23
    50303089000 ANGEL PIECE '97
    ANGEL PIECE '97
  • 24
    31007107001 PVC-HOSE 6X9 MM PER METER
    PVC-HOSE 6X9 MM PER METER
  • 25*
    78035027133 RADIATORHOSE CPL. W. Y-ITEM
    RADIATORHOSE CPL. W. Y-ITEM
  • 30
    78035026033 RADIATOR H. CPL. W.THERM.75 08
    RADIATOR H. CPL. W.THERM.75 08
  • 31
    0770320020 O-RING 32,00X2,00
    O-RING 32,00X2,00
  • 32
    59435017000 THERMOSTAT 70 DEGREE 04
    THERMOSTAT 70 DEGREE 04
  • 33
    0016040183 SCREW FOR PLASTIC D=4X18
    SCREW FOR PLASTIC D=4X18
  • 34
    7733503400030 RADIATOR PROTECTION BLACK 07
    RADIATOR PROTECTION BLACK 07
  • 35
    77335073000 HOSE CONNECTOR 4 STROKE 07
    HOSE CONNECTOR 4 STROKE 07
  • 40
    41001052000 RUBBER SLEEVE D=12MM
    RUBBER SLEEVE D=12MM
  • 41
    77335001000 WASHER FOR RADIATOR 08
    WASHER FOR RADIATOR 08
  • 42
    0023060123 COLLAR SCREW M6X12 TX
    COLLAR SCREW M6X12 TX
  • 60
    59011079000 FAN WIRING HARNESS 2001
    FAN WIRING HARNESS 2001
  • 61
    58011109105 FUSE 5 A 2003
    FUSE 5 A 2003
  • 63
    0603142015 ALU SEALRING DIN7603-14X20X1,5
    ALU SEALRING DIN7603-14X20X1,5
  • 64
    78035045000 THERMOSWITCH 95-100 DG
    THERMOSWITCH 95-100 DG
  • 65
    58435041000 FAN CPL. 12V LC4 2000
    FAN CPL. 12V LC4 2000
  • 66
    0081500181 SCREW FOR PLASTIC D=5X18
    SCREW FOR PLASTIC D=5X18
  • 67
    78035043000 FAN SUPPORT EXC 08
    FAN SUPPORT EXC 08
  • 68
    0011400800 RIVET 4,0X 8 ALU
    RIVET 4,0X 8 ALU
